Any one have this charger?Dynamite Passport UltraForce 200W charger,I need opinions. >

Any one have this charger?Dynamite Passport UltraForce 200W charger,I need opinions.

Any one have this charger?Dynamite Passport UltraForce 200W charger,I need opinions.

Old 08-22-2013, 02:49 PM
  #1
Tech Master
Thread Starter
iTrader: (2)

Markcuda's Avatar

Join Date: Mar 2013
Location: Clinton,Illinois-Mark Smith
Posts: 1,363
Trader Rating: 2 (100%+)
Questions?? Any one have this charger?Dynamite Passport UltraForce 200W charger,I need opinions.

I was thinking of a new charger, it must be ac/dc, 10 amps is very
much OK with me.
Has any one had any problems with this charger?

----------------------------------------------------
Dynamite’s Passport UltraForce produces up to 200W of charge power with AC/DC input voltage and an array of features that certain to catch the eye of even the most avid of RC enthusiasts. The UltraForce pumps out up to 10 amps of continuous current and up to 5 amps of discharge current. The charger sports an anodised black aluminium faceplate with brushed aluminium accents, easy-to-use push button navigation and enough power to sufficiently charge high capacity batteries with 1-3C charge rates.


----------------------------------------------------
Features
- 200W charge power
- Adjustable charge current range of 0.1 to 10.0A
- Charges LiPo/Life (1-6Cells), NiCD/NiMH (1-18 cells) and Pb/SLA type batteries (2-24V)
- Adjustable discharge current range of 0.1 to 5.0A
- Comes with Tamiya, Deans and Traxxas connectors as well as a JST-XH balance adapter
- Integrated 1-6S LiPo balance circuit
- Battery fast charge mode
- Battery storage mode
- Internal cooling fan
- Low input voltage, over current protection, over temperature, reverse polarity and short circuit protection
- Store and run feature
Markcuda is offline
Old 08-24-2013, 01:57 PM
  #2
Tech Master
Thread Starter
iTrader: (2)

Markcuda's Avatar

Join Date: Mar 2013
Location: Clinton,Illinois-Mark Smith
Posts: 1,363
Trader Rating: 2 (100%+)
Default

Anyone?
Markcuda is offline
Old 08-27-2013, 03:25 AM
  #3
Tech Regular

Bigwave's Avatar

Join Date: Jun 2011
Location: Calgary, Alberta
Posts: 398
Default

I have one and it's worked great all season. I parallel charge 2x4s lipos with it on a regular basis with ease. Easy to transport too since it isn't too large considering how powerful it is.
Bigwave is offline
Old 08-27-2013, 02:30 PM
  #4
Tech Master
Thread Starter
iTrader: (2)

Markcuda's Avatar

Join Date: Mar 2013
Location: Clinton,Illinois-Mark Smith
Posts: 1,363
Trader Rating: 2 (100%+)
Default

Dave, thank you.
After searching the net, there are allot of ac/dc-10amp chargers.
Right now, I have a Onyx 235, 6 amp is all I can charge on AC.
Markcuda is offline
Old 08-28-2013, 01:31 AM
  #5
Tech Regular

Bigwave's Avatar

Join Date: Jun 2011
Location: Calgary, Alberta
Posts: 398
Default

The biggest reason I bought it wasn't the 10 amps, it's the 200w of output. Hard to find that many watts of power with an all in one AC charger. At least it was when I looked this past winter.
Bigwave is offline
Old 09-02-2013, 05:42 AM
  #6
Tech Master
Thread Starter
iTrader: (2)

Markcuda's Avatar

Join Date: Mar 2013
Location: Clinton,Illinois-Mark Smith
Posts: 1,363
Trader Rating: 2 (100%+)
Default

Well, I ordered this charger from Amain, got it
for 80 bucks= free shipping.
Markcuda is offline
Old 09-02-2013, 06:42 AM
  #7
Tech Master
iTrader: (25)

spookie's Avatar

Join Date: Jan 2013
Posts: 1,944
Trader Rating: 25 (100%+)
Default

We have two of the dynamite passports, and had another in the past. We both like ours. Good all around reasonably priced charger. I'm not sure if all the chargers do this, but my version of the charger reduces the charge rate when one cell is over 100Mv (1/10 volt) out of balance. The full charge rate won't kick in until all cells get within that range. It doesn't pull the high cell down, it trickle charges the low cell. But all in all, I like the passports, nice bang for the buck.

Sons version


My version/ I charge @ 8 amps always.
spookie is offline
Old 09-02-2013, 06:47 AM
  #8
Tech Master
Thread Starter
iTrader: (2)

Markcuda's Avatar

Join Date: Mar 2013
Location: Clinton,Illinois-Mark Smith
Posts: 1,363
Trader Rating: 2 (100%+)
Default

On my Onyx 235, I can only charge at 6 amps(AC)
For my 7.4V/7200/70Cs, at 6 amps, it takes 65 minutes.
I hope I can cut that time down a bit
I also like that I can use the storage feature.
Markcuda is offline
Old 09-02-2013, 06:57 AM
  #9
Tech Master
iTrader: (25)

spookie's Avatar

Join Date: Jan 2013
Posts: 1,944
Trader Rating: 25 (100%+)
Default

Nice charger Mark. I think on mine, the discharge threshold is set for 3.0volts and can't be changed, at least I haven't been able to change it. I usually just cut off the charge or discharge around 3.8v for storage. The only other one I would consider getting is the Onyx 245, for dual charging batteries, since I run 2X2S (2S, 4S) and 2X3S (3S) duals exclusively.
spookie is offline
Old 06-07-2014, 05:24 AM
  #10
Tech Rookie

Join Date: Jun 2014
Posts: 2
Default Passport ultraforce

This may sound silly but I have just purchased the Dymamite Passport Ultraforce 200w charger and I am wondering where you plug in a Ni-Mh battery? Theres aplace on the side that looks like it would fit but it says Temp sensor. Can someone help?
Cuppycat is offline
Old 06-07-2014, 08:25 AM
  #11
Tech Champion

Join Date: Oct 2007
Posts: 7,342
Default

Originally Posted by Cuppycat View Post
This may sound silly but I have just purchased the Dymamite Passport Ultraforce 200w charger and I am wondering where you plug in a Ni-Mh battery? Theres aplace on the side that looks like it would fit but it says Temp sensor. Can someone help?
Need to plug in to the main round banana ports to charge it. Probably need an adapter to convert between whichever connector your ni-mh has to bananas. Not the temp sensor port. I'm guessing it is a receiver pack?
Dave H is offline
Old 06-07-2014, 08:46 AM
  #12
Tech Master
iTrader: (25)

spookie's Avatar

Join Date: Jan 2013
Posts: 1,944
Trader Rating: 25 (100%+)
Default

Just grab you one of these.

19 Mega Squid RC Charge Plug Adapter
http://www.ebay.com/itm/New-Multi-19...item20e47600d7
spookie is offline
