Default Own Build Help Needed

ello,
I am currently bulid a radio control car (about 1/5 scale), it is my first ever build and am not fimiler with what I need in the way of Recever and Transmitter etc there seems lots of choice and I dont know where to start!

I am Buliding it with a 50cc 2 stroke chainsaw engine.

I am a Engineer so know about the engine and have sorted the frame, suspension, engine stearing etc, but feel I need pointing it the right direction with the electrics.

Many Thanks
grizzleigh is offline
Reply With Quote
Old 01-30-2012, 07:03 PM
  #2
Tech Adept
iTrader: (3)

Join Date: Jan 2012
Location: Ludington, MI
Posts: 183
Trader Rating: 3 (100%+)
Default

How many servos are you runnin, if its just throttle/brake and steering.

I would recamend Futaba 3PMX great radio, for the money, with lots of range and a third channel for a kill switch.

I would definatly put in a kill switch, this one...

http://www.davesmotors.com/s.nl/c.88...t.A/id.3569/.f

Oh ya and...

looseman1 is offline
Reply With Quote
Old 01-31-2012, 04:53 PM
  #3
Tech Fanatic

Join Date: Sep 2010
Location: Norheimsund, Norway
Posts: 783
Default

Depending on the weight of your car, one or maybe two Hitec HS-805 MG will be sufficient. These are reasonible priced and are pretty strong. I use one of these in my home made 1/5-scale car which are weighed in at about 13 kg using 1/5 onroad wheels.
Lars in Norway is offline
Reply With Quote
Old 02-02-2012, 02:23 AM
  #4
Tech Adept
iTrader: (15)

xlamontx's Avatar

Join Date: Jun 2005
Location: A track near you...
Posts: 209
Trader Rating: 15 (100%+)
Default

Hi Grizz, welcome to the forum. I use a Futaba 3PK on my 1/5 scale cars. I chose this transmitter because of the "brake mix" feature. My cars have separate front and rear brakes and servos respectfully and this feature allows me to apply a higher percentage of brake pressure to the front brakes versus the rear to prevent lock up in the rear. I can also program a 1/2 second delay to the servo that controls the rear brakes. I added the SPEKTRUM 2.4 system to my transmitter a few years ago and it has been trouble free.
xlamontx is offline
Reply With Quote
Old 02-02-2012, 04:40 PM
  #5
Tech Fanatic

Join Date: Sep 2010
Location: Norheimsund, Norway
Posts: 783
Default

What he said ^^ bar the Spektrum system I use my 3PK for my electric cars now, and a 4PK for my large scales. A bit on the expensive side, if i had waited a bit i would have bought the 4PL instead, a lot cheaper but with almost all the functions that the 4PK has. I like the brake mix a lot.
Lars in Norway is offline
Reply With Quote
