Mugen MBX8

    Hide Wikipost
Old 03-15-2019, 09:38 PM   -   Wikipost
R/C Tech ForumsThread Wiki: Mugen MBX8
Please read: This is a community-maintained wiki post containing the most important information from this thread. You may edit the Wiki once you have been a member for 90 days and have made 90 posts.

Last edit by: E1 Diablo
E2021 - MBX8 1/8 Nitro Buggy Kit

Chassis:
The MBX8 chassis features a new design that improves traction and stability in bumpy conditions and on the exit of corners. The steering post are also keyed into the MBX8 chassis for easier maintenance.

Differential & drive train:
High Traction Differentials are included in the MBX8. The Mugen Seiki HTD provides increased acceleration, longer runtime, and more consistent handling. The HTD's also increase stability, traction, and improve handling in bumpy conditions. The HTD has a new larger volume diff cup to increase consistency during long main events. This makes it easier to time rhythm sections, better in bumpy and low grip conditions, helps to increase traction, and increases fuel mileage.

The new gearbox makes allows you to remove and service the differentials without detaching the suspension arm mounts. Easy access to the front and rear differential.

New straight cut 13T bevel gear & 44T conical gear. The new straight cut bevel and conical gears increase acceleration, runtime, and efficiency. A free and efficient drive train will also increase speeds while cornering.

Light weight one-piece wing mount:
The new lightweight one-piece wing mount lower the center of gravity. The position of the wing and wing mount is optimized to improve the performance of vehicle. The height of the wing mount is adjustable. This allows you to control the down force on the rear of the vehicle by simply raising or lowering the mount on the shock tower.

Light weight high down-force wing:
The new IFMAR legal wing is lightweight and provides amazing down force and cornering. The underside of the wing uses a new design to reduced weight and creates additional down-force.

Suspension:
New suspension mounts. The FF/FR/RF/RR are new for the MBX8.
The front and rear lower arms use a new impact resistant material for increased durability. The new arms are box-shaped and include arm stiffeners to reduce flex and increase durability. Adjusting the hardness of the lower suspension arms is now possible. This allows you to fine tune the steering and traction from track to track. CFRP plates will be released as an option part.

Center differential mount & plate:
The center differential mounts use a stiffer material and has a new top plate to reduce chassis flex and increases clutch bell, spur gear, and clutch bearing life. The reduced chassis flex also provides more consistent handling in all conditions. The top plate design also makes it easier to adjust the brakes and easier maintenance.

Enclosed Battery box and updated carbon fiber radio plate:
The MBX8 still uses a flat 2S Lipo or Life battery, but the receiver battery is now enclosed in a molded battery box. The battery box allows for quick and easy access to the battery. The molded box also helps protect the battery from hard impacts. The battery box is mounted to an updated carbon fiber radio plate.

Other new parts and upgrades:
Body, Clamping Servo Saver Nut, F/R Shock Towers, Front bumper, Front center and rear center universal joint.

Mugen Seiki MBX8 Manual

Print Wikipost

Reply

Old 07-19-2018, 05:47 AM
  #646
Tech Elite
iTrader: (4)

KINGZJ's Avatar

Join Date: Sep 2001
Location: South Milwaukee,WISCONSIN
Posts: 2,286
Trader Rating: 4 (100%+)
Default

Why are people using other than Mugen parts on this car? I have at least 4 gallons through mine and have yet to find the need to use any other manufactuers parts. O wait I supose I do have kyosho fuel line on my car and a jconcepts body.
KINGZJ is offline
Reply With Quote
Old 07-19-2018, 06:22 AM
  #647
Tech Regular
iTrader: (1)

Join Date: Dec 2016
Posts: 492
Trader Rating: 1 (100%+)
Default

Originally Posted by KINGZJ View Post
Why are people using other than Mugen parts on this car? I have at least 4 gallons through mine and have yet to find the need to use any other manufactuers parts. O wait I supose I do have kyosho fuel line on my car and a jconcepts body.
Because I have a Buku clutch and the Mugen bell doesn't fit well with it. And I want the 15T cb. Mugen doesn't have one.
Cardiak is offline
Reply With Quote
Old 07-19-2018, 07:07 AM
  #648
Tech Regular
iTrader: (9)

Join Date: Mar 2008
Posts: 330
Trader Rating: 9 (100%+)
Default

What lipo are we using for our mbx8? Want the flashpoint but it’s out of stxock at amain...
mattythegreat is offline
Reply With Quote
Old 07-19-2018, 09:49 AM
  #649
Tech Fanatic
iTrader: (17)

Maxxingout's Avatar

Join Date: Dec 2010
Posts: 786
Trader Rating: 17 (100%+)
Default

https://www.amainhobbies.com/protek-...tk-5196/p15789

This is the one I'm using. Fits nice with plenty of wire room.
mattythegreat likes this.
Maxxingout is offline
Reply With Quote
Old 07-19-2018, 10:30 AM
  #650
Tech Elite
iTrader: (4)

KINGZJ's Avatar

Join Date: Sep 2001
Location: South Milwaukee,WISCONSIN
Posts: 2,286
Trader Rating: 4 (100%+)
Default

Originally Posted by Cardiak View Post
Because I have a Buku clutch and the Mugen bell doesn't fit well with it. And I want the 15T cb. Mugen doesn't have one.

I really wasnt refering to your post. Im not a fan of the buku but I know many who like it. I do question the 15t clutch bell thats huge. Must be a large track or your engine is a stump puller.
KINGZJ is offline
Reply With Quote
Old 07-19-2018, 12:23 PM
  #651
Tech Fanatic

tom1974's Avatar

Join Date: Jan 2013
Location: la maddalena italy
Posts: 875
Default

Originally Posted by Maxxingout View Post
https://www.amainhobbies.com/protek-...tk-5196/p15789

This is the one I'm using. Fits nice with plenty of wire room.
noooo....it's more expensive
tom1974 is offline
Reply With Quote
Old 07-19-2018, 12:30 PM
  #652
Tech Fanatic

tom1974's Avatar

Join Date: Jan 2013
Location: la maddalena italy
Posts: 875
Default

https://www.amainhobbies.com/mugen-seiki-15t-clutch-bell-muge0709/p29906
tom1974 is offline
Reply With Quote
Old 07-19-2018, 01:40 PM
  #653
Tech Regular
iTrader: (1)

Join Date: Dec 2016
Posts: 492
Trader Rating: 1 (100%+)
Default

Originally Posted by KINGZJ View Post
I really wasnt refering to your post. Im not a fan of the buku but I know many who like it. I do question the 15t clutch bell thats huge. Must be a large track or your engine is a stump puller.
I have a 7tr with a 28-8 for bashing. I posted in this thread because it's far more active.
Cardiak is offline
Reply With Quote
Old 07-19-2018, 07:04 PM
  #654
Tech Regular
iTrader: (9)

Join Date: Mar 2008
Posts: 330
Trader Rating: 9 (100%+)
Default

Can someone give me the dimensions of the battery box.. Trying to order a lipo on the cheap side and need to k ow where I need to be. My buggy won’t get here till next week.
mattythegreat is offline
Reply With Quote
Old 07-19-2018, 07:10 PM
  #655
Tech Regular
iTrader: (1)

Join Date: Dec 2016
Posts: 492
Trader Rating: 1 (100%+)
Default

Originally Posted by mattythegreat View Post
Can someone give me the dimensions of the battery box.. Trying to order a lipo on the cheap side and need to k ow where I need to be. My buggy won’t get here till next week.
I believe the Flash Point pack will restock at Amain on 8/2 if you can wait a couple of weeks.
mattythegreat likes this.
Cardiak is offline
Reply With Quote
Old 07-20-2018, 04:32 AM
  #656
Tech Fanatic
iTrader: (17)

Maxxingout's Avatar

Join Date: Dec 2010
Posts: 786
Trader Rating: 17 (100%+)
Default

noooo....it's more expensive
They go for the same price on a-main
https://www.amainhobbies.com/protek-...tk-5196/p15789

https://www.amainhobbies.com/flash-p...pr2001/p496158
Maxxingout is offline
Reply With Quote
Old 07-20-2018, 05:24 AM
  #657
Tech Fanatic

tom1974's Avatar

Join Date: Jan 2013
Location: la maddalena italy
Posts: 875
Default

You Can Buy hobby King Life or lipo
tom1974 is offline
Reply With Quote
Old 07-20-2018, 11:14 AM
  #658
Tech Fanatic

tom1974's Avatar

Join Date: Jan 2013
Location: la maddalena italy
Posts: 875
Default


jmoneym and debocurl5.0 like this.
tom1974 is offline
Reply With Quote
Old 07-20-2018, 11:17 AM
  #659
Tech Fanatic

tom1974's Avatar

Join Date: Jan 2013
Location: la maddalena italy
Posts: 875
Default


flap jack and debocurl5.0 like this.
tom1974 is offline
Reply With Quote
Old 07-22-2018, 10:06 AM
  #660
Tech Initiate

R4ge's Avatar

Join Date: Jul 2017
Location: Larisa, Greece
Posts: 22
Default

Hi to all!
New here and new owner of mbx8!
mattythegreat likes this.
R4ge is offline
Reply With Quote
