Smile Vantomme Car Designs

A dream of creating my car was finally realised in 2005 with the Vantomme M1.1
(a concept car based on the SpeedMerchant Rev4).
The first try was merely a check whether the carbon fibre supplier could do the job...
He did a superb one, so my ambition was now a truly own design...

A few corrections were made to the very first design:
1)numerous chassis cut-outs
2)extreme small lower motor plate for easy access motor
3)a sharp X shape front design
4)a very short chassis with an extra bumper to attach
5)own designing using AutoCAD program to realy fine-tune the chassisline

For more 'first' pics:
http://mrcw.be/wordpress/?p=13

The 'VantommeM12' (2007/09) hit the circuit for the very first time last weekend, this during a 'MRCZ Challenge race' (qualified in 2nd, 3rd in race),
battling with CorallySP12M, Hotbodies Cyclone12, CRC T-fource and L4's. Further testing and exploration of the car its possibilities are sheduled!
Attached Thumbnails
Vantomme Car Designs-m12.jpg   Vantomme Car Designs-m12-3-.jpg   Vantomme Car Designs-m12-9-.jpg

Last edited by Benedict; 05-02-2008 at 07:46 PM.
Benedict is offline   Reply With Quote
Old 09-20-2007, 10:25 AM   #2
Tech Apprentice

Join Date: Mar 2005
Location: Belgium
Posts: 53
Exclamation High-resolution picture chassis design

High-res pic Vantomme M12

Greetz, Benedict.
Benedict is offline   Reply With Quote
Old 11-26-2007, 07:55 PM   #3
Tech Adept

RcLoCo Online's Avatar

Join Date: Jan 2005
Location: South South Bronx
Posts: 137
Default

Quote:
Originally Posted by Benedict View Post
High-res pic Vantomme M12

Greetz, Benedict.
anything else on this car??
__________________
{Mugen Seiki } { RB Concept }
{ Team Durango { JP Motors }
{K.O. PROPO } {SERPENT 811, FOREVER WAITING ON SERVO FIX!!} Nuff Said!!!!
RcLoCo Online is offline   Reply With Quote
Old 04-22-2008, 03:04 PM   #4
Tech Apprentice

Join Date: Mar 2005
Location: Belgium
Posts: 53
Exclamation New 'Arrow' (sneak preview)

"New" prototype car by vantomme : Arrow.

Sneak preview:
Arrow 02
Arrow 03

Ideas...
- starting point: no 'traditional' battery location
- create some space for electronics (pretty hard with battery placement)
- rear suspension : CRC/Speedmerchant based (springs/tubes)
- rear pod : center pivot based CRC x-pod
- rear pod : V-dezign pod

Following soon...
*More pics on vantomme-Arrow
*Update on vantomme-M12 (new chassis + Arrow rear design)
*1/10th pan car (Arrow based + 4 cell + 200mm like CRC / SpeedM / BMI )
*Carbon axle spacers
* ...
__________________
- Vantomme LMP12 > 100% lipo <
- Vantomme M12
- Vantomme E12
- Vantomme M10
Benedict is offline   Reply With Quote
Old 04-22-2008, 03:14 PM   #5
Tech Elite

RCSteve93's Avatar

Join Date: Dec 2005
Location: Long Island, New York
Posts: 4,601
Trader Rating: 11 (100%+)
Default

Quote:
Originally Posted by Benedict View Post
"New" prototype car by vantomme : Arrow.

Sneak preview:
Arrow 02
Arrow 03

Ideas...
- starting point: no 'traditional' battery location
- create some space for electronics (pretty hard with battery placement)
- rear suspension : CRC/Speedmerchant based (springs/tubes)
- rear pod : center pivot based CRC x-pod
- rear pod : V-dezign pod

Following soon...
*More pics on vantomme-Arrow
*Update on vantomme-M12 (new chassis + Arrow rear design)
*1/10th pan car (Arrow based + 4 cell + 200mm like CRC / SpeedM / BMI )
*Carbon axle spacers
* ...
Very nice job. I always dream of doing the same. Hopefully next year after I take CAD/CAM at my school, I will be able to design and build my own 12th too.
__________________
rm -rf /windows
RCSteve93 is offline   Reply With Quote
Old 04-22-2008, 03:20 PM   #6
Tech Apprentice

Join Date: Mar 2005
Location: Belgium
Posts: 53
Default

Thanks RCSteve.
Once you get started with CAD/CAM and master the basics,
it's really great to design... and to keep on designing...
(really need to spend more time on racing instead of
designing ...)
__________________
- Vantomme LMP12 > 100% lipo <
- Vantomme M12
- Vantomme E12
- Vantomme M10
Benedict is offline   Reply With Quote
Old 04-22-2008, 05:57 PM   #7
Tech Adept

Join Date: Feb 2006
Posts: 151
Trader Rating: 5 (100%+)
Default

Benedict,
car looks great congrats.
__________________
Frank Connolly
Thugs Bunny is offline   Reply With Quote
Old 05-02-2008, 07:32 PM   #8
Tech Apprentice

Join Date: Mar 2005
Location: Belgium
Posts: 53
Default Vantomme M12 (BL edition) & Arrow

New pics of the M12 (BL edition) & the all new Arrow chassis design:

The weight of the cars ( 2,4 mm carbon chassis) is considerably lower
than the previous versions ... (864gr)
(fully loaded, with Novak BL - as shown on pics)
M12 : 845 gr
Arrow : 834 gr

Both cars will use the V-dezign motorpod (red Arrow now shown with CRC pod), but lower motor plate has an extra hole for the left hub so that the
'old' Asso/CRC style motorpod can be used.

Front suspension is pretty standard, every Asso-inspired (Asso L4, CRC pro-strut, IRS, old skool, ...) front arm fits the chassis.

M12 (BL edition)
M12 (rear view)
Arrow + M12 BL

BR,
Benedict
__________________
- Vantomme LMP12 > 100% lipo <
- Vantomme M12
- Vantomme E12
- Vantomme M10
Benedict is offline   Reply With Quote
Old 05-02-2008, 07:44 PM   #9
Tech Apprentice

Join Date: Mar 2005
Location: Belgium
Posts: 53
Default Arrow

More pics of the Arrow :

Arrow
Arrow (side view)
Arrow (side view2)
Arrow (front)
Arrow (silver/V-dezign)

With an extreme short chassis, well placed cut-outs and 2.4mm thick, the Arrow turns out to be a very strong and lightweight chassis; only 33 gr!! (without bumper), making it a very light 1/12th car...

More to follow
__________________
- Vantomme LMP12 > 100% lipo <
- Vantomme M12
- Vantomme E12
- Vantomme M10
Benedict is offline   Reply With Quote
Old 05-05-2008, 10:18 PM   #10
Tech Adept

Join Date: Aug 2004
Posts: 137
Default

come on Benedict-

Sure the chassis looks nice ... but when it comes right down to it you are just making something that someone else has already done. Just like all those other teebar cars out there. Why not design your own rear pod with something other than a Associated front end. Now then you would have my attention. Be original!
cookie1 is offline   Reply With Quote
Old 05-06-2008, 04:58 AM   #11
Tech Elite

joe of loath's Avatar

Join Date: Mar 2007
Location: Bristol, England, United Kingdom
Posts: 4,857
Trader Rating: 1 (100%+)
Default

Quote:
Originally Posted by RCSteve93 View Post
Very nice job. I always dream of doing the same. Hopefully next year after I take CAD/CAM at my school, I will be able to design and build my own 12th too.
persuading them is the hard part. my teacher is so afraid of it it's unreal.
__________________
HPI E-Firestorm - Tamiya TA05 racer (carbon chassis, 10.5 brushless etc) - LRP Blast S10 BX - Revo 2.5r truggy conversion (in progress)
joe of loath is offline   Reply With Quote
Old 05-06-2008, 05:00 AM   #12
Tech Apprentice

Join Date: Mar 2005
Location: Belgium
Posts: 53
Default Original?

Quote:
Originally Posted by cookie1 View Post
come on Benedict-

Sure the chassis looks nice ... but when it comes right down to it you are just making something that someone else has already done.
Yes, exactly, another 1/12th car

Quote:
Just like all those other teebar cars out there.
... you've got a good point... it is maybe time that I start off with an own designed t-bar car...

Quote:
Why not design your own rear pod with something other than a Associated front end.
Now that's a good question with a very simple answer: money and resources! I feel already lucky I have found someone who can create customized (= original?) carbon parts for me. Would I love to create my own pod? yes sir! but you are not talking to a company like CRC, Corally,... just a hobbyist having a great time creating his own race car(chassis) if I find someone who can do it (pod), I'll keep you posted!

Quote:
Now then you would have my attention.
I believe I already have ...

Quote:
Be original!
That's not my greatest concern when deciding on the pod, front and rear suspension... I choose to look at (proven) functionality and simplicity (in use),
and for the carbon parts... they are original
__________________
- Vantomme LMP12 > 100% lipo <
- Vantomme M12
- Vantomme E12
- Vantomme M10
Benedict is offline   Reply With Quote
Old 05-06-2008, 06:12 AM   #13
Tech Apprentice

Join Date: Mar 2005
Location: Belgium
Posts: 53
Default

Quote:
The weight of the cars ( 2,4 mm carbon chassis) is considerably lower than the previous versions ... (864gr)
(fully loaded, with Novak BL - as shown on pics)
M12 : 845 gr
Arrow : 834 gr
The Arrow with brushed ESC and motor reaches 825 gr!

After the first run with the M12, I must say it is a very fast car!
FRONT
springs : 0.022
suspension : old skool
tires : jaco 2xpink

REAR
springs : white
tube lube : CRC red
tires : jaco yellow

Center spring : gold / 30wt oil

Just not enough steering, so will go for 0.020 or 0.018 front spring
or for jaco black / gray tires.
The chassis itself provides lots of grip, for indoor carpet racing
a bit too much => too much flex (better for outdoor/asphalt?)
=> maybe look for a 3.0 mm thick chassis for carpet ?

Also thinking about moving the side links (chassis points) a bit more to the front and the inside (thanks to the wider chassis I have plenty of space to do so top view). I'm curious about
the effect (if any) on entering corners ! (see CRC - Battle Axe- - they placed there links -on chassis- more on the inside)
__________________
- Vantomme LMP12 > 100% lipo <
- Vantomme M12
- Vantomme E12
- Vantomme M10

Last edited by Benedict; 05-06-2008 at 06:53 AM.
Benedict is offline   Reply With Quote
Old 05-06-2008, 03:47 PM   #14
Tech Fanatic

trailranger's Avatar

Join Date: Feb 2007
Location: Springfield, MO
Posts: 946
Default

Benidict, Great work!

The arrow looks to be a killer car. Reminds me of my Darkside MX2 but with GREAT improvements over the Inline Battery design: Larger area for ESC, Refined Upper Battery holddown, Lower Super Structure.

You mentioned the car had a push, is that because there is little weight transfer when slowing down for corners? I remember my MX2 was a killer car for sweepers and highspeed corners just I had to really slow down for infield.
trailranger is offline   Reply With Quote
Old 05-06-2008, 04:17 PM   #15
Tech Champion

Join Date: Nov 2001
Location: Hawaii, USA
Posts: 7,186
Default

The upper battery mount looks nicer then the Darkside but I prefer the posts in front of the battery like the Darkside. A fairly hard accident is going to eject the battery right through the servo.

Overall a nice looking car though. I really like the way you did the side spring mounts.
InspGadgt is offline   Reply With Quote
