Tamiya M-08

Old 07-05-2019, 07:09 AM
  #166
Tech Adept

JD Skyline's Avatar

Join Date: May 2009
Location: Tamiya County
Posts: 158
Default

Great review.. keep them reviews on the M-08 coming ErikJan.. I'm in the proces of buying an M chassis. Not sure yet what chassis to buy. Used to drive a M-05 ver2 and liked it very much. Think that a M08 will be a challenge to drive and get it dailed...Thanx
JD Skyline is offline
Old 07-05-2019, 09:04 AM
  #167
Tech Elite
iTrader: (1)

Join Date: Sep 2010
Location: Chicagoland
Posts: 2,101
Trader Rating: 1 (100%+)
Default

My screws just arrived,so I can build the M08. Yay! (I order hex head screws.... steel ones are cheap.)
Nerobro is offline
Old 07-06-2019, 02:47 AM
  #168
Tech Adept

ErikJan's Avatar

Join Date: Oct 2013
Location: Eindhoven, the Netherlands
Posts: 129
Default

Update, and not a nice one.
Shorty LiPo is NO direct fit. The 4/5mm holes are complete covered by the side holders. No way to get the plugs in in a normal way. Only a low (22mm) LiPo could be connected with some force.
Looks like the shorty lipo concept had not been landed at the Tamiya design offices.
ErikJan is offline
Old 07-06-2019, 10:07 AM
  #169
Tech Master
iTrader: (28)

MrLesac's Avatar

Join Date: Jan 2005
Location: Omaha, NE
Posts: 1,740
Trader Rating: 28 (100%+)
Default

Was reading tcs rules and it states that you cannot use parts intended for one car on another, but if they are basically the same part, for example m06 aluminum rear hubs on an 08, is this acceptable. Not trying to find a speed secret, more or less trying not to spend so much money, and use what I have haha.
MrLesac is offline
Old 07-06-2019, 11:39 AM
  #170
Tech Elite
iTrader: (73)

Raman's Avatar

Join Date: Aug 2007
Location: Las Vegas
Posts: 4,088
Trader Rating: 73 (100%+)
Default

Originally Posted by MrLesac View Post
Was reading tcs rules and it states that you cannot use parts intended for one car on another, but if they are basically the same part, for example m06 aluminum rear hubs on an 08, is this acceptable. Not trying to find a speed secret, more or less trying not to spend so much money, and use what I have haha.
Technically no. Most of the parts for M07 can be used for M08. M06 is a different series.. so TCS rules would not allow it.

I havent looked close enough .. are the hubs close?
Raman is offline
Old 07-06-2019, 12:30 PM
  #171
Tech Master
iTrader: (28)

MrLesac's Avatar

Join Date: Jan 2005
Location: Omaha, NE
Posts: 1,740
Trader Rating: 28 (100%+)
Default

Originally Posted by Raman View Post


Technically no. Most of the parts for M07 can be used for M08. M06 is a different series.. so TCS rules would not allow it.

I havent looked close enough .. are the hubs close?
have not verified, but a quick glance they look very close.
MrLesac is offline
Old 07-06-2019, 08:18 PM
  #172
Tech Rookie

Join Date: Sep 2007
Location: Colorado
Posts: 5
Default

Originally Posted by MrLesac View Post
Was reading tcs rules and it states that you cannot use parts intended for one car on another, but if they are basically the same part, for example m06 aluminum rear hubs on an 08, is this acceptable. Not trying to find a speed secret, more or less trying not to spend so much money, and use what I have haha.
if I recall correctly, the M05/M06 rear hubs have toe built into them and the M07/M08 hubs have none. All the toe is at the inner rear suspension arm mounts.
rippen and eR1c like this.
TRFBlueMan is offline
Old 07-10-2019, 09:04 PM
  #173
Tech Adept
iTrader: (1)

Join Date: Sep 2010
Location: Brea, Ca
Posts: 135
Trader Rating: 1 (100%+)
Default

Just my 2 cents. Maybe that is all it will be worth. I got my M08 built except for the electronics installation. In looking at all of the parts on this chassis vs the M07, I think the 08 is better engineered and easier to work on. The steering is more secure to the chassis, and I think the mid-motor will be a benefit over the M06. I built it with most of the available hop ups but used the steel screws. I'm interested in seeing the weight with a normal weight body (MX-5). I just need a good base spring and oil set up to get this on the track. Black carpet will be my first run in another two weeks. Looking forward to driving the rig. I committed. I sold all of my other minis, so no backing out now
eR1c likes this.
EB Racer is offline
Old 07-13-2019, 02:56 AM
  #174
Tech Adept

ErikJan's Avatar

Join Date: Oct 2013
Location: Eindhoven, the Netherlands
Posts: 129
Default

Another 150+ laps, about an hour tracktime. Still the m08 is about 0.4s off the m07 laptimes, but now much easier and consistent.
The front stabi is an improvement, as is some thicker diff oil (5k).
What worries me is the slop/play in the steering. After every tight corner you must make steering corrections due to the play. We tried the usual tricks like glue on the posts and shims, but the result is limited. Best solution will be to flip the servo, and connect the steering links direct to the servosaver. We will do as soon as the Bparts will be available, because a modified brace must be made.
eR1c likes this.
ErikJan is offline
Old 07-13-2019, 06:59 AM
  #175
Tech Elite
iTrader: (73)

Raman's Avatar

Join Date: Aug 2007
Location: Las Vegas
Posts: 4,088
Trader Rating: 73 (100%+)
Default

Originally Posted by ErikJan View Post
Another 150+ laps, about an hour tracktime. Still the m08 is about 0.4s off the m07 laptimes, but now much easier and consistent.
The front stabi is an improvement, as is some thicker diff oil (5k).
What worries me is the slop/play in the steering. After every tight corner you must make steering corrections due to the play. We tried the usual tricks like glue on the posts and shims, but the result is limited. Best solution will be to flip the servo, and connect the steering links direct to the servosaver. We will do as soon as the Bparts will be available, because a modified brace must be made.
did you install o-ring between ball cups and rod ends? That will take play out of steering as well.
Raman is offline
Old 07-13-2019, 02:53 PM
  #176
Tech Elite
iTrader: (2)

eR1c's Avatar

Join Date: Oct 2010
Posts: 2,398
Trader Rating: 2 (100%+)
Default

Update, and not a nice one.
Shorty LiPo is NO direct fit. The 4/5mm holes are complete covered by the side holders. No way to get the plugs in in a normal way. Only a low (22mm) LiPo could be connected with some force.
Looks like the shorty lipo concept had not been landed at the Tamiya design offices.
For what it is worth, using a shorty LiPo pack in the M07 seemed like an after-thought to Tamiya too. It doesn't work w/o some slight modification (namely including foam or something on each end so it fits correctly). There are some parts on ShapeWays that are a nice fix to this issue, yet I doubt they are TCS legal. Also to balance a shorty pack in the M07 also presents problems as the battery holes are lined up w/ the chassis brace.
eR1c is offline
Old 07-14-2019, 05:21 PM
  #177
Tech Champion
iTrader: (105)

Core Creations's Avatar

Join Date: Sep 2001
Location: Back in the booth
Posts: 5,991
Trader Rating: 105 (100%+)
Default

Core Creations is offline
Old 07-14-2019, 08:21 PM
  #178
Tech Master
iTrader: (84)

Join Date: Aug 2002
Location: Maryland
Posts: 1,308
Trader Rating: 84 (100%+)
Default

got to race my m08 this weekend, outdoor asphalt, med grip. mostly just a test and tune. the car is light, I had a shorty pack, sweep 40/33 tires, and a lightweight MX-5 body. Had to find 140g (had to use a 8300 full size pack for the main to pass tech.) TCS trim will make 1300g easier. car has lots of potential and is already close.

eR1c, I just double side tape my shorty batteries in for the M07, stays put and makes offsetting the balance easy. For the M08 I just use double side tape on the bottom of the battery in the center section of the chassis. 2 pieces up against the plastic chassis on either side. prevents the battery from sliding out (also using the recommended foam piece in the battery area, shown in the manual)
eR1c likes this.
Markus is offline
Old 07-14-2019, 11:52 PM
  #179
Tech Adept

Aitutaki's Avatar

Join Date: Aug 2012
Location: Austria
Posts: 192
Default

Hy Guys,

After driving my M06 from 2012 to 2013, and switching back to M05 in 2014 for some racing ambition reasons, i now decided to buy this RWD M-Chassis too, as i am a M-Chassis addicted guy
So i could not await to build and testdrive it.





After a lot of Laps i realized, that the Shorty Lipo let the M08 spin out during acceleration, and a full size lipo is way better to drive. I guess that is the reason, why they did not myke a design for shortys...
I switched to Full size, but the only big issue with this car is the bad steering.
Or better: it will not return to neutral. Thats why after some turns you have to carfully speed up , and this will be a disadvantage when fighting against M07....




and fnally i can run my 210 Mini Body Shell again on my M08 thats great




rccartips, MatsNorway and eR1c like this.
Aitutaki is offline
Old 07-15-2019, 07:28 AM
  #180
Tech Addict

Join Date: Jul 2009
Posts: 542
Default

I would like to hear more about tuning and how it is to drive
MatsNorway is offline
