Go Back  R/C Tech Forums > General Forums > Electric Off-Road
Losi 1/10 TEN-SCTE ARR 4x4 Short Course Truck Thread >

Losi 1/10 TEN-SCTE ARR 4x4 Short Course Truck Thread

Like Tree9Likes

Losi 1/10 TEN-SCTE ARR 4x4 Short Course Truck Thread

Old 02-08-2012, 04:52 AM
  #28981
Tech Master
iTrader: (11)

FLHX1550's Avatar

Join Date: Mar 2010
Location: Wyoming, MN
Posts: 1,712
Trader Rating: 11 (100%+)
Default

Originally Posted by Mxer59 View Post
I also saw these they look good and priced very well anyone running these, is sensorless a big deal? Or sensored better I was looking at 4600kv or 5100kv
Viper did allot of R&D to get the Copperhead to be very smooth and drive-able, and kind of took a "clean-slate" approach to developing a sensor-less system. Though it is a "sensor-less" system, it performs nothing like sensor-less systems that came before it.

Reminder, neither the 540/3900kv, the 550/5150kv or the 550/4500kv systems ARE ROAR LEGAL!!!!

The systems were really focused at the basher / hobbyist level market to replace and/or upgrade people in the RTR market. With those thoughts in mind, Viper built the motors to be as efficient as possible at a fair price. Unfortunately that required going outside of the ROAR spec's for the motors, but that was never the intent with the system.

Given the durability/performance of the Copperhead, we are finding they are kind of filling a "void" in the racing market for a simple and affordable system for the 4wd SCT class. Where they are and are not allowed to run is up to the people having the races, and I suggest you check with them to determine if they are legal or not to race there.

Last edited by FLHX1550; 02-08-2012 at 05:33 AM.
FLHX1550 is offline
Old 02-08-2012, 05:02 AM
  #28982
Tech Adept
iTrader: (41)

Join Date: Oct 2010
Location: Northern lower Michigan
Posts: 133
Trader Rating: 41 (100%+)
Default

I am talking about the small piece that bolts flat to the shock tower with 4 screws around the diff housing, and the front bumper braces to it with two screws.
TheRevolution is offline
Old 02-08-2012, 05:33 AM
  #28983
Tech Master
iTrader: (1)

shinnbad12's Avatar

Join Date: Jun 2008
Location: eureka IL.
Posts: 1,143
Trader Rating: 1 (100%+)
Default

Originally Posted by TheRevolution View Post
I am talking about the small piece that bolts flat to the shock tower with 4 screws around the diff housing, and the front bumper braces to it with two screws.
This piece would be nice to see it in a cnc alluminum upgrade.

Scott
shinnbad12 is offline
Old 02-08-2012, 06:39 AM
  #28984
Tech Elite
iTrader: (121)

ChrisAttebery's Avatar

Join Date: Oct 2009
Location: Gilroy, CA
Posts: 2,258
Trader Rating: 121 (100%+)
Default

Look up Kick Angle on any of the available tuning guides.


Originally Posted by HighLife420 View Post
Hey guys, got my tuning kit installed, all but the front hinge pin holder. I was wondering something, looking at the diagram, it shows the the values as

Angle 8-9-10-11-12

What do these values represent?
ChrisAttebery is offline
Old 02-08-2012, 06:50 AM
  #28985
Tech Fanatic
iTrader: (2)

Join Date: Feb 2008
Posts: 778
Trader Rating: 2 (100%+)
Default

Originally Posted by shinnbad12 View Post
This piece would be nice to see it in a cnc alluminum upgrade.

Scott
Yes, yes!!! This one of the piece's I keep breaking!!!!! It should be made aluminum. 100%
LosiMadMan is offline
Old 02-08-2012, 07:05 AM
  #28986
Tech Master
iTrader: (49)

HighLife420's Avatar

Join Date: Oct 2011
Location: Fort Lauderdale, FL
Posts: 1,189
Trader Rating: 49 (100%+)
Default

Originally Posted by ChrisAttebery View Post
Look up Kick Angle on any of the available tuning guides.
Ah, thank you...couldnt figure the name of the adjustment.

What is the stock front give you in terms of value? (8-9-10-11-12)

Im hearing that 0 inserts for both (10) is the normal and best setting overall?
HighLife420 is offline
Old 02-08-2012, 07:19 AM
  #28987
Tech Initiate

Join Date: Oct 2011
Posts: 29
Default

Originally Posted by "Smiley" View Post
Another win for the scte. This past weekend was Rd 1 of the Rc Pro Texas State Series hosted by Mikes Hobby Shop/Gulf Coast Raceway in Porter, Tx. I TQ'ed and Won with the scte. There were almost 60 entries in the 4wd Sc Class. The truck was flawless all weekend.
What setup do you run at Mikes?? I dont know if I will ever race but would like to setup my truck to perform well at that track.
dmwilson09 is offline
Old 02-08-2012, 07:41 AM
  #28988
Tech Elite
iTrader: (86)

gawith0413's Avatar

Join Date: Aug 2011
Location: Springfield, MO
Posts: 2,681
Trader Rating: 86 (100%+)
Default

Originally Posted by Casper View Post
I would start there for sure. It is a great base setup.
Hey Casper,
What does it mean on Aaron setup:

http://www.losi.com/ProdInfo/Files/L...Lane-JBRL4.pdf

The rear suspension anti-squat: 3(using aluminum pivot supports). Is 3 the insert your suppose to use. Front or back? Thanks
gawith0413 is offline
Old 02-08-2012, 07:45 AM
  #28989
Tech Addict
iTrader: (19)

SNR Graphite's Avatar

Join Date: May 2011
Location: So Cal
Posts: 586
Trader Rating: 19 (100%+)
Default



SNR Graphite is offline
Old 02-08-2012, 07:52 AM
  #28990
Tech Master
iTrader: (11)

FLHX1550's Avatar

Join Date: Mar 2010
Location: Wyoming, MN
Posts: 1,712
Trader Rating: 11 (100%+)
Default

Originally Posted by gawith0413 View Post
Hey Casper,
What does it mean on Aaron setup:

http://www.losi.com/ProdInfo/Files/L...Lane-JBRL4.pdf

The rear suspension anti-squat: 3(using aluminum pivot supports). Is 3 the insert your suppose to use. Front or back? Thanks
3 is the angle (3 degrees of Anti-Squat). Use a #1 pill in the front block on the rear bulkhead, with the hole in the "up" position

0 pill is 2 deg Anti-Squat, .5 up is 2.5, 1 up is 3. .5 down is 1.5, 1 down is 1 deg

The pills in the back block are for adjusting rear toe-in
FLHX1550 is offline
Old 02-08-2012, 08:06 AM
  #28991
Tech Elite
iTrader: (86)

gawith0413's Avatar

Join Date: Aug 2011
Location: Springfield, MO
Posts: 2,681
Trader Rating: 86 (100%+)
Default

Originally Posted by FLHX1550 View Post
3 is the angle (3 degrees of Anti-Squat). Use a #1 pill in the front block on the rear bulkhead, with the hole in the "up" position

0 pill is 2 deg Anti-Squat, .5 up is 2.5, 1 up is 3. .5 down is 1.5, 1 down is 1 deg

The pills in the back block are for adjusting rear toe-in
I think I'm starting to understand this. Thank you very much!!!
gawith0413 is offline
Old 02-08-2012, 08:08 AM
  #28992
Tech Adept
iTrader: (3)

Join Date: Nov 2011
Location: San Diego, CA
Posts: 190
Trader Rating: 3 (100%+)
Default

Originally Posted by easye View Post
I boiled all my bumper peices for 30 mins havnt broke a single peice since.
Right, I have yet to try this, but it was recommended to me by someone at Losi who posts on this thread.
AgroAMG is offline
Old 02-08-2012, 08:13 AM
  #28993
Tech Adept
iTrader: (3)

Join Date: Nov 2011
Location: San Diego, CA
Posts: 190
Trader Rating: 3 (100%+)
Default broken tlr rear hinge pin holder

I'm probably the only person to have ever broken this piece. Once this happens even if you replace the plastic insert, it just continues to break the new plastic inserts as the aluminum isn't there to provide support anymore.

AgroAMG is offline
Old 02-08-2012, 08:26 AM
  #28994
Tech Elite
iTrader: (86)

gawith0413's Avatar

Join Date: Aug 2011
Location: Springfield, MO
Posts: 2,681
Trader Rating: 86 (100%+)
Default

Originally Posted by AgroAMG View Post
I'm probably the only person to have ever broken this piece. Once this happens even if you replace the plastic insert, it just continues to break the new plastic inserts as the aluminum isn't there to provide support anymore.

That sucks!!!
gawith0413 is offline
Old 02-08-2012, 08:59 AM
  #28995
Tech Fanatic

.AJ.'s Avatar

Join Date: Oct 2011
Location: Basingstoke UK
Posts: 756
Default

what is the diff ratio of this truck?????
.AJ. is offline
