Team Associated B74 4wd buggy

    Hide Wikipost
Old 06-07-2019, 11:25 AM   -   Wikipost
R/C Tech ForumsThread Wiki: Team Associated B74 4wd buggy
Please read: This is a community-maintained wiki post containing the most important information from this thread. You may edit the Wiki once you have been a member for 90 days and have made 90 posts.

Last edit by: mes
B74 Manual
New parts list
Product page
petitrc set-up page
Pistons explained

B64 carry-over parts:

- front and rear wheels
- springs
- pistons
- plastic diff gears
- shock caps
- spring cups
- arm mount inserts
- ball cups
- wing
- clamping wheel hexes
- generic hardware, tools, fluids
- ...

Fan mount: Revolution Design Yokomo YZ.4SF Aluminium Fan Mount RDRP0474

Gear chart:

Print Wikipost

Reply

Old 06-12-2019, 07:16 AM
  #346
Tech Elite
iTrader: (136)

timannnn6's Avatar

Join Date: Jul 2010
Posts: 2,200
Trader Rating: 136 (100%+)
Default

Originally Posted by TonyCooperUK View Post
Hi from the UK, just finishing up building the B74, think I must have had a Friday afternoon packed special as most things were in wrong bags, and mine had bright yellow add on instructions sheet hahahaha

its all gone together very well, I do however have 1 gearbox slightly noiser than the other

I was slowly turning spur gear and can feel a very slight tight spot, so removed front diff, and the tight spot remained, replaced it and removed rear, its gone, so I know its rear gearbox

I have done 1 shim a side, and 2 shims same sides

all I can think of now is to strip the diff itself and rotate the crowngear, maybe something is running out in that?

built it pretty much kit to start with, except the spacers on steering, dang who wants that much bumpsteer LOL
Try pulling diff out and spinning 180 and putting back in. Another thing you can try is taking gear off diff and mounting using different holes (spin 1 or 2 holes from where it was mounted). There is a high spot somewhere and changing mounting locations usually resolves. Then try 2 shims on non gear side. The shims are .25mm so if you have any .1mm or .2mm you can try that as well. Once I messed with mine a little there is no drag at all and it spins super free now.

Hope that helps.
JeepnMike likes this.
timannnn6 is offline
Reply With Quote
Old 06-12-2019, 09:12 AM
  #347
mes
Tech Master

Join Date: Aug 2009
Posts: 1,515
Default

Originally Posted by TonyCooperUK View Post
Hi from the UK, just finishing up building the B74, think I must have had a Friday afternoon packed special as most things were in wrong bags, and mine had bright yellow add on instructions sheet hahahaha

its all gone together very well, I do however have 1 gearbox slightly noiser than the other

I was slowly turning spur gear and can feel a very slight tight spot, so removed front diff, and the tight spot remained, replaced it and removed rear, its gone, so I know its rear gearbox

I have done 1 shim a side, and 2 shims same sides

all I can think of now is to strip the diff itself and rotate the crowngear, maybe something is running out in that?

built it pretty much kit to start with, except the spacers on steering, dang who wants that much bumpsteer LOL
I had to sand the bottom of one of the pinions on mine a bit as there was some residue left from the coating process.
mes is offline
Reply With Quote
Old 06-12-2019, 11:45 AM
  #348
Tech Apprentice
iTrader: (2)

RDucky47's Avatar

Join Date: May 2010
Location: Lake Zurich, IL
Posts: 90
Trader Rating: 2 (100%+)
Default

Originally Posted by mes View Post
I had to sand the bottom of one of the pinions on mine a bit as there was some residue left from the coating process.

i just had had the same problem. Isolated to the pinion gear mesh. I moved shims etc etc.

i ended up swapping the front and rear diffs and itís good now. Front is shimmed 1/1, rear 0/2 (gear side 0).
RDucky47 is offline
Reply With Quote
Old 06-12-2019, 11:47 AM
  #349
Tech Apprentice
iTrader: (2)

RDucky47's Avatar

Join Date: May 2010
Location: Lake Zurich, IL
Posts: 90
Trader Rating: 2 (100%+)
Default

Originally Posted by Kepner View Post
My kit had both screws for the front and rear diff. The front holds that little bitty piece of the body on to the diff cover, The same place you mount the front wing. The rear just has the screw. Does that screw hole actually go all the way through into the diff housing? If so you should probably put a set screw in there to seal it up.

the screw hole in the top middle of the case does not go all the way through. Problem solved.
RDucky47 is offline
Reply With Quote
Old 06-12-2019, 05:17 PM
  #350
Tech Regular
iTrader: (15)

JeepnMike's Avatar

Join Date: Dec 2010
Location: Enumclaw, WA (TRCR)
Posts: 490
Trader Rating: 15 (100%+)
Default

Originally Posted by RDucky47 View Post



i just had had the same problem. Isolated to the pinion gear mesh. I moved shims etc etc.

i ended up swapping the front and rear diffs and itís good now. Front is shimmed 1/1, rear 0/2 (gear side 0).
I just did the same thing on both ends of mine, ring gear side zero shims, carrier side 2 shims, it is buttery smooth now and notably quieter. I think in all of that tinkering, I learned that the quick-access covers (I call them escape hatches) for the differentials are fan-freaking tastic... Being able to pull the differentials for service in under 2 mins is unheard of.. Great job AE!!

Has anybody found chassis protectors anywhere yet? I haven't seen any aftermarket, and AE appears to still be out of stock.
JeepnMike is offline
Reply With Quote
Old 06-12-2019, 05:28 PM
  #351
Tech Elite
iTrader: (136)

timannnn6's Avatar

Join Date: Jul 2010
Posts: 2,200
Trader Rating: 136 (100%+)
Default

OCRC has chassis protectors.
JeepnMike likes this.
timannnn6 is offline
Reply With Quote
Old 06-13-2019, 03:21 AM
  #352
Tech Rookie

Join Date: Oct 2016
Posts: 9
Default

anyone got a lot of endfloat on the slipper assembly, mines 0.6mm can see it floating back and forward while sat on the stand and throttle trimmed up to run the gearboxes etc

bearings are moving back and forth in the uprights, really dont like that, shims on order to sort

my rear diff issue was improved by removing the crown gear and rotating it round 180 degree, I have marked the case and gear to avoid it happening again
the rear box still noisier than the front, but will assess it again after the weekend when if its dry I get to run it for the first time
TonyCooperUK is offline
Reply With Quote
Old 06-13-2019, 08:00 AM
  #353
Tech Initiate

Kepner's Avatar

Join Date: May 2019
Location: Washington
Posts: 28
Default

Originally Posted by JeepnMike View Post
Has anybody found chassis protectors anywhere yet? I haven't seen any aftermarket, and AE appears to still be out of stock.
You can find uncut protectors on eBay. That's what I got.

JeepnMike and TonyCooperUK like this.
Kepner is offline
Reply With Quote
Old 06-13-2019, 03:51 PM
  #354
Tech Initiate

Join Date: May 2016
Posts: 33
Default

Originally Posted by JeepnMike View Post
I just did the same thing on both ends of mine, ring gear side zero shims, carrier side 2 shims, it is buttery smooth now and notably quieter. I think in all of that tinkering, I learned that the quick-access covers (I call them escape hatches) for the differentials are fan-freaking tastic... Being able to pull the differentials for service in under 2 mins is unheard of.. Great job AE!!

Has anybody found chassis protectors anywhere yet? I haven't seen any aftermarket, and AE appears to still be out of stock.
my gear boxes also sounded loud and not smooth i messed with them for about a hour what i ended up doing was 1 shim ring gear side and 2 shims carrier side so 3 in all
taking the shim out of gear side felt like bearing was rubbing it needed the shim to give bearing and gear room also it changes gear mesh
I think the diff felt a little loose side to side in the case so the slop was changing diff pinion mesh to the tight side by adding 1 shim to carrier side made the gear box run much smoother with a more consistent gear mesh I did use a small amount of black grease
ratititat is offline
Reply With Quote
Old 06-13-2019, 04:45 PM
  #355
Tech Regular
iTrader: (14)

thirtydaZe's Avatar

Join Date: Feb 2016
Location: Omaha
Posts: 416
Trader Rating: 14 (100%+)
Default

Subscribing.
thirtydaZe is offline
Reply With Quote
Old 06-13-2019, 10:21 PM
  #356
Super Moderator

b1narych0ice's Avatar

Join Date: Nov 2014
Location: Milwaukee, WI
Posts: 168
Default

Got mine on the track today, all smiles. Put down some hot laps that were faster than my 64 ever went on the second battery in slow track conditions (slashes and dust), and my 64 was no slouch. I had more off-power steering than I needed and seemed like it had a lot of droop in the front, but it still had plenty of on power steering and easily cleared the big triple for 5 minutes. The car consistently jumped farther than I expected it to, which took some getting used to but is awesome.

Went with Dustinís setup for 13.5 indoor dirt with center diff and plastic gears. 1730g with a full size shorty, but I think I may go right to a low profile pack to shave 50g. Still a long way from min weight, but thereís plenty of room for lightened titanium money pits...

Motor came off at 110F with a fan after 10 minutes with 24/72 gearing, so I think this is a pretty good starting point for 13.5.
Sm1983 and JeepnMike like this.
b1narych0ice is offline
Reply With Quote
Old 06-13-2019, 11:00 PM
  #357
mes
Tech Master

Join Date: Aug 2009
Posts: 1,515
Default

Check out the Performa Racing 4000 mAh packs to save even more weight. They are very popular in our club.
mes is offline
Reply With Quote
Old 06-14-2019, 10:36 AM
  #358
Tech Initiate

Kepner's Avatar

Join Date: May 2019
Location: Washington
Posts: 28
Default Everyone likes pictures. For everyone still waiting on there kit.







I love building shocks...
​​​​​​And yes I know my anttena is hideous. I got an anttena less RX now.

This is the first body I have painted with the intent to look good in about forever years.. next time I'll play with mask.
FastPete and JeepnMike like this.

Last edited by Kepner; 06-14-2019 at 11:13 AM.
Kepner is offline
Reply With Quote
Old 06-14-2019, 12:41 PM
  #359
Tech Champion
iTrader: (44)

FastPete's Avatar

Join Date: Jan 2009
Posts: 5,255
Trader Rating: 44 (100%+)
Default

Ok building myself one, instruction manual says shock eyelets, front long rear short. The supplemental instruction sheet says both long? I assume both long is correct?
FastPete is offline
Reply With Quote
Old 06-14-2019, 10:06 PM
  #360
Tech Addict
iTrader: (15)

Join Date: Nov 2007
Posts: 579
Trader Rating: 15 (100%+)
Default

So does anyone know why they didnít make the rear arms like the b6.1 shock location mounts
speed101 is offline
Reply With Quote
