Old 05-29-2014, 01:07 PM   #3556
Tech Elite

brothainchrist0's Avatar

Join Date: Apr 2010
Location: Nebraska
Posts: 3,002
Trader Rating: 144 (100%+)
Default

Hi Mr Uriah,

I had you modify a Picco .12 Red Dot for me last season and I absolutely love the engine and it's performance. This year I upgraded the exhaust system for it and actually bought the pipe that was meant to run with this motor and it got even faster! I was inspecting the motor this last weekend and noticed that there was a pretty good gap between the cooling head and the actual motor case but it was filled with the top of the sleeve. All the bolts are tight as well. Is this the way it has always been and I am just now noticing it or is the sleeve backing out?

Thank you sir and you do some amazing work. You will be touching all of my motors from now on as long as you are willing

Thanks again!
Kyle
210-722-6891
__________________
Mugen MRX5 - Ielasi Modified Engines/Matrix Tires/Savox Servos/Airtronics Radio

IGT Hobbies - The one stop shop for anything on-road and incredible customer service.
brothainchrist0 is offline   Reply With Quote
Old 05-29-2014, 03:01 PM   #3557
Tech Lord

wingracer's Avatar

Join Date: Nov 2007
Posts: 12,636
Trader Rating: 21 (100%+)
Default

That's normal, see this pic:

http://www.ofna.com/images/engines/e...ot-on-road.jpg
__________________
Sean. Certified speed crazed mowron.
Team Shepherd USA
www.ashfordhobby.com
wingracer is offline   Reply With Quote
Old 05-29-2014, 03:37 PM   #3558
Tech Master

Grinder's Avatar
R/C Tech Elite Subscriber

Join Date: Feb 2003
Posts: 1,847
Trader Rating: 2 (100%+)
Default

Quote:
Originally Posted by TeamCarnage View Post
A little debate ensued Sunday that I need cleared up. Are the Nova Pre-run engines truly broke in and ready for optimum race tuning out of the box?
I would suggest running about 5 tanks. Starting very rich, gradually leaning to race tune.

They are ready to go, but I suggest the quick breakin to get the internals used to your fuel.
__________________
www.murnanmodified.com
Grinder is offline   Reply With Quote
Old 05-29-2014, 03:40 PM   #3559
Tech Master

Grinder's Avatar
R/C Tech Elite Subscriber

Join Date: Feb 2003
Posts: 1,847
Trader Rating: 2 (100%+)
Default

Quote:
Originally Posted by brothainchrist0 View Post
Hi Mr Uriah,

I had you modify a Picco .12 Red Dot for me last season and I absolutely love the engine and it's performance. This year I upgraded the exhaust system for it and actually bought the pipe that was meant to run with this motor and it got even faster! I was inspecting the motor this last weekend and noticed that there was a pretty good gap between the cooling head and the actual motor case but it was filled with the top of the sleeve. All the bolts are tight as well. Is this the way it has always been and I am just now noticing it or is the sleeve backing out?

Thank you sir and you do some amazing work. You will be touching all of my motors from now on as long as you are willing

Thanks again!
Kyle
210-722-6891
Thanks Kyle. Yes, it is normal to see the entire lip of the sleeve on that engine.
__________________
www.murnanmodified.com
Grinder is offline   Reply With Quote
Old 05-31-2014, 09:11 AM   #3560
Tech Elite

ToysRUsKid's Avatar

Join Date: Jul 2008
Location: Cinncinati, OH
Posts: 2,590
Trader Rating: 15 (100%+)
Send a message via AIM to ToysRUsKid
Default

Uriah, which bearing puller do you use for the keep-on motors? I have some older keep-ons i want to replace the rear bearing in and my Hudy puller is having a hard time with the rear bearing. I have the 18 part to put a new one in but the stock puller setup isn't working well to get it out.
__________________
Dorian Tisdale - Professional RC Driver Wannabe
RC America \ DeSoto Racing \ XRay \ Novarossi
www.tsrcar.com \ Red Mosquito raceway \ www.racersoftoledo.com \ www.midwestseries.com
ToysRUsKid is offline   Reply With Quote
Old 06-02-2014, 05:12 PM   #3561
Tech Adept

Flyin Hawaiian1's Avatar

Join Date: Jan 2014
Location: Downingtown, PA
Posts: 146
Default TQ and 1st place finish at Prairie Land Shootout in Joliet IL.

The Murnan modified ISON GT engine helped me captured the TQ and 1st place finish at the Prairie Land Shootout in Leisure Hours Raceway over the weekend. Thank you Uriah for your fantastic work!!!



__________________
Andy Liu "Flyin' Hawaiian"
2015 teams/sponsors:
Serpentamerica/Desoto Racing, Murnan Modified Motors, VP powermaster Fuel, Sweep Racing USA, Speed Passion, BUKU performance products
Flyin Hawaiian1 is offline   Reply With Quote
Old 06-02-2014, 07:12 PM   #3562
Tech Master

Grinder's Avatar
R/C Tech Elite Subscriber

Join Date: Feb 2003
Posts: 1,847
Trader Rating: 2 (100%+)
Default

Quote:
Originally Posted by ToysRUsKid View Post
Uriah, which bearing puller do you use for the keep-on motors? I have some older keep-ons i want to replace the rear bearing in and my Hudy puller is having a hard time with the rear bearing. I have the 18 part to put a new one in but the stock puller setup isn't working well to get it out.
I use the KM tool. It's like the hudy. You have to be careful. Find the edge of the bearing with the tool. Then expand the collet. If you stick it all the way in like normal, the collet will expand on the case, damaging it.

Make sure your installers are relieved for front, and rear bearing inner races. If they are flat, your damaging the bearings just by installing them. The inner races on some novarossi bearings stick out past the outer race. The Virtus is one of those.
__________________
www.murnanmodified.com
Grinder is offline   Reply With Quote
Old 06-02-2014, 07:13 PM   #3563
Tech Master

Grinder's Avatar
R/C Tech Elite Subscriber

Join Date: Feb 2003
Posts: 1,847
Trader Rating: 2 (100%+)
Default

Nicely done!!

Quote:
Originally Posted by Flyin Hawaiian1 View Post
The Murnan modified ISON GT engine helped me captured the TQ and 1st place finish at the Prairie Land Shootout in Leisure Hours Raceway over the weekend. Thank you Uriah for your fantastic work!!!



__________________
www.murnanmodified.com
Grinder is offline   Reply With Quote
Old 06-02-2014, 08:35 PM   #3564
Tech Champion

FastPete's Avatar
R/C Tech Elite Subscriber

Join Date: Jan 2009
Posts: 5,202
Trader Rating: 44 (100%+)
Default

Quote:
Originally Posted by Flyin Hawaiian1 View Post
The Murnan modified ISON GT engine helped me captured the TQ and 1st place finish at the Prairie Land Shootout in Leisure Hours Raceway over the weekend. Thank you Uriah for your fantastic work!!!



Yes Uriah is the best! Ran a modded Bonito last year, and need a ISON fast!

Congrats Andy and Mike, that's me in 3rd.
__________________
Authorized Dealer for /Agama / Tekno / Team Associated / Schelle / Hobbywing / PT Racing Shock & Diff oil / Serpent / Tekin / JConcepts / AKA / Proline / Savox / M2C / Picco / www.fiercercsolutions.com Like us on facebook www.facebook.com/FierceRCSolutions
FastPete is offline   Reply With Quote
Old 06-02-2014, 08:40 PM   #3565
Tech Master

TeamCarnage's Avatar

Join Date: Aug 2004
Location: Highland In. USA
Posts: 1,466
Trader Rating: 21 (100%+)
Default

I'm having trouble finding the answer. I have a R3 engine that needs a rod soon. Which Nova will work. Can't cross reference anywhere. tia
__________________
Nick Altieri
TeamNitro RC Club, New Home track- Ho Chunk Southland Expo, Lynwood IL
Serpent 748 Natrix TQ, PICCO EMX-WC or "R", Spektrum DX4RPro, Futaba servos
411,3.0 17.5 TC; 3.5 Mod Sedan HobbyWing
Please drive responsibly
TeamCarnage is offline   Reply With Quote
Old 06-03-2014, 04:27 AM   #3566
Tech Master

GREGORY!'s Avatar

Join Date: Jun 2006
Location: Greece
Posts: 1,064
Trader Rating: 1 (100%+)
Default

novarossi 7601.
__________________
" kyosho rrr wc-team orion crf "
" serpent 966-mega zx21 EM "
" mugen mbx6-picco p7r evo 2 "
GREGORY! is offline   Reply With Quote
Old 06-03-2014, 08:18 AM   #3567
Tech Master

TAMAK's Avatar

Join Date: Nov 2008
Posts: 1,915
Trader Rating: 28 (100%+)
Default

Any word on the performance capability of the ISON .12? is it similar to the 353?
__________________
TrakPower Speed Equipment / Speed Passion
Serpent Natrix 748 TQ - Nova REX
D413 Reventon 1.1ex 13.5t; AE B6d Laydown Reventon Pro 1.1
DNX408V2-NovaP5, DETC410-Reventon 1.1ex-5.5t MMM
RC10 , RC10GT2- CV-R- SAVOX,
TAMAK is offline   Reply With Quote
Old 06-06-2014, 02:14 PM   #3568
Tech Master

Grinder's Avatar
R/C Tech Elite Subscriber

Join Date: Feb 2003
Posts: 1,847
Trader Rating: 2 (100%+)
Default

Quote:
Originally Posted by TeamCarnage View Post
I'm having trouble finding the answer. I have a R3 engine that needs a rod soon. Which Nova will work. Can't cross reference anywhere. tia
07601
__________________
www.murnanmodified.com
Grinder is offline   Reply With Quote
Old 06-06-2014, 02:15 PM   #3569
Tech Master

Grinder's Avatar
R/C Tech Elite Subscriber

Join Date: Feb 2003
Posts: 1,847
Trader Rating: 2 (100%+)
Default

Quote:
Originally Posted by TAMAK View Post
Any word on the performance capability of the ISON .12? is it similar to the 353?
I have not played with the ISON .12 yet.
__________________
www.murnanmodified.com
Grinder is offline   Reply With Quote
Old 06-06-2014, 09:02 PM   #3570
Tech Elite

ToysRUsKid's Avatar

Join Date: Jul 2008
Location: Cinncinati, OH
Posts: 2,590
Trader Rating: 15 (100%+)
Send a message via AIM to ToysRUsKid
Default

Quote:
Originally Posted by Grinder View Post
07601
As long as the Max part will fit, i have one laying around you can have Nick. It has the same part number so I think it works.
__________________
Dorian Tisdale - Professional RC Driver Wannabe
RC America \ DeSoto Racing \ XRay \ Novarossi
www.tsrcar.com \ Red Mosquito raceway \ www.racersoftoledo.com \ www.midwestseries.com
ToysRUsKid is offline   Reply With Quote
