Old 04-23-2012, 04:12 PM   #541
Tech Fanatic

subaru73's Avatar

Join Date: Jul 2005
Location: Auburn
Posts: 884
Trader Rating: 41 (100%+)
Default rm01

here a pictures of my rm01 just waiting for the center shock.
Attached Thumbnails
Tamiya 1/12 R/C RM-01 "Racing Master"-043.jpg   Tamiya 1/12 R/C RM-01 "Racing Master"-044.jpg   Tamiya 1/12 R/C RM-01 "Racing Master"-045.jpg   Tamiya 1/12 R/C RM-01 "Racing Master"-046.jpg
__________________
Tamiya 419 Tamiya evo5 ms,Tamiya Ta05r Tamiya FF04 rm01 Tamiya Ff03R
Ko proppo K.I.Y radio lrp speed control
Cfx paint works Fantom Racing Ko Proppo apex Rc tq hobbies acer racing Hebki design works
subaru73 is offline   Reply With Quote
Old 04-23-2012, 04:31 PM   #542
Tech Champion

RedBullFiXX's Avatar
R/C Tech Elite Subscriber

Join Date: Mar 2003
Location: Intergalactic Planetary
Posts: 6,539
Trader Rating: 34 (100%+)
Default

Quote:
Originally Posted by subaru73 View Post
here a pictures of my rm01 just waiting for the center shock.
Nice ride

Couple tips
1>Remove the zip tie holding the wires on the pod
12th scale pods need to be free & smooth
Ideally you would want shorter, thinner (16g) gauge wire as well

2>Move the steering links to the front of the servo saver for better ackerman
__________________
--> 12th scale Information Source <--

"Men do not quit playing because they grow old; they grow old because they quit playing."
― Oliver Wendell Holmes Jr.
RedBullFiXX is offline   Reply With Quote
Old 04-23-2012, 07:11 PM   #543
Tech Fanatic

subaru73's Avatar

Join Date: Jul 2005
Location: Auburn
Posts: 884
Trader Rating: 41 (100%+)
Default rm01

great tips will do.
__________________
Tamiya 419 Tamiya evo5 ms,Tamiya Ta05r Tamiya FF04 rm01 Tamiya Ff03R
Ko proppo K.I.Y radio lrp speed control
Cfx paint works Fantom Racing Ko Proppo apex Rc tq hobbies acer racing Hebki design works
subaru73 is offline   Reply With Quote
Old 04-27-2012, 07:57 PM   #544
Tech Elite

spring71's Avatar

Join Date: Oct 2008
Location: Chino, CA
Posts: 3,698
Trader Rating: 3 (100%+)
Smile

Newman Joest Racing Porsche kit and Adjustable Metal Upright - F103 F104 RM01 is in stock at TQ.



Click here to visit RM01 parts store.

FYI, Thanks.
__________________
TQ RC RACING
Indoor RC Race Track & Hobby Shop in Chino, CA
Online Shop
http://www.tqrcracing.com
tq@tqrcracing.com
spring71 is offline   Reply With Quote
Old 04-27-2012, 11:11 PM   #545
Tech Master

madjack's Avatar

Join Date: Sep 2002
Location: Orange County
Posts: 1,735
Trader Rating: 18 (100%+)
Send a message via Yahoo to madjack
Default

Finished! Thanks to the TQ crew, looking forward to the TCS race next month at TQ -
Attached Thumbnails
Tamiya 1/12 R/C RM-01 "Racing Master"-rm01a.jpg   Tamiya 1/12 R/C RM-01 "Racing Master"-rm01b.jpg
madjack is offline   Reply With Quote
Old 04-28-2012, 12:08 AM   #546
Tech Fanatic

Taman's Avatar

Join Date: Jun 2008
Location: GC, Aust
Posts: 833
Trader Rating: 64 (100%+)
Default

Nice work! The new decals are really sticky, do you guys use detergent or anything on the decal, to slide into place and then let it dry?
__________________
Toms 84C, Nissan R91CP, Porsche 956, TRF 417 V5.
Taman is offline   Reply With Quote
Old 04-28-2012, 01:57 PM   #547
Tech Master

madjack's Avatar

Join Date: Sep 2002
Location: Orange County
Posts: 1,735
Trader Rating: 18 (100%+)
Send a message via Yahoo to madjack
Default

Quote:
Originally Posted by Taman View Post
Nice work! The new decals are really sticky, do you guys use detergent or anything on the decal, to slide into place and then let it dry?
some use Windex, I just cut them out and went for it
madjack is offline   Reply With Quote
Old 04-28-2012, 03:26 PM   #548
Tech Fanatic

Taman's Avatar

Join Date: Jun 2008
Location: GC, Aust
Posts: 833
Trader Rating: 64 (100%+)
Default

Quote:
Originally Posted by madjack View Post
some use Windex, I just cut them out and went for it
lol your a brave man these new Tamiya decals are super sticky compared to what they used to be like.
__________________
Toms 84C, Nissan R91CP, Porsche 956, TRF 417 V5.
Taman is offline   Reply With Quote
Old 04-30-2012, 10:01 AM   #549
Tech Fanatic

bakaguyjean's Avatar

Join Date: Apr 2007
Location: Atsugi Japan
Posts: 823
Trader Rating: 1 (100%+)
Default

Does anybody know if the U.S. Spec Corally wheels are offset,I am trying to keep the car narrow,and the Ennti tires are not sold here.
Im looking for 1mm to 3mm offset.
Im hope the Corally wheels will work I am running a narrow body and I have been cutting non offset wheels.
Thanks in advance
bakaguyjean is offline   Reply With Quote
Old 04-30-2012, 11:03 AM   #550
Tech Champion

RedBullFiXX's Avatar
R/C Tech Elite Subscriber

Join Date: Mar 2003
Location: Intergalactic Planetary
Posts: 6,539
Trader Rating: 34 (100%+)
Default

Quote:
Originally Posted by bakaguyjean View Post
Does anybody know if the U.S. Spec Corally wheels are offset,I am trying to keep the car narrow,and the Ennti tires are not sold here.
Im looking for 1mm to 3mm offset.
Im hope the Corally wheels will work I am running a narrow body and I have been cutting non offset wheels.
Thanks in advance
I had previously thought the Enetti would work, but, Jaco/Parma wheels have the most off-set, so if you want to keep it narrow, those are the best bet
Rear wheels will go right to the edge of the body, front wheels have too much off-set compared to the Tamiya wheels

Here are my recommendations based on test & racing so far
For Carpet Jaco Rear white dot, with Tamiya Option front
For Outdoor Tamiya Kit Rear, with Tamiya Option Front

Enetti are similar to the CRC wheels, with almost no off-set

Gratz to Dave Garcia with his new RM-01, hitting the podium at the TQ 2nd Anniversary Race
First time out with the car, looking good

__________________
--> 12th scale Information Source <--

"Men do not quit playing because they grow old; they grow old because they quit playing."
― Oliver Wendell Holmes Jr.

Last edited by RedBullFiXX; 04-30-2012 at 11:36 AM.
RedBullFiXX is offline   Reply With Quote
Old 04-30-2012, 11:55 AM   #551
Tech Master

Join Date: Sep 2009
Posts: 1,898
Trader Rating: 9 (100%+)
Default

Quote:
Originally Posted by spring71 View Post
Newman Joest Racing Porsche kit and Adjustable Metal Upright - F103 F104 RM01 is in stock at TQ.



Click here to visit RM01 parts store.

FYI, Thanks.
Will those uprights allow enough height adjustment to use standard height fronts?
__________________
Kyosho Inferno MP9 TKI4
TLR 22 3.0
Apex RC Proshop
inpuressa is offline   Reply With Quote
Old 04-30-2012, 12:56 PM   #552
Tech Champion

RedBullFiXX's Avatar
R/C Tech Elite Subscriber

Join Date: Mar 2003
Location: Intergalactic Planetary
Posts: 6,539
Trader Rating: 34 (100%+)
Default

Quote:
Originally Posted by inpuressa View Post
Will those uprights allow enough height adjustment to use standard height fronts?
Yes,with those you can run a Tamiya wheel down to the rim, but they still have the same axle specs, so not enough off-set for standard 12th scale front wheels, and also still metric, not standard size

12th scale spindles are coming
__________________
--> 12th scale Information Source <--

"Men do not quit playing because they grow old; they grow old because they quit playing."
― Oliver Wendell Holmes Jr.
RedBullFiXX is offline   Reply With Quote
Old 04-30-2012, 03:37 PM   #553
Tech Master

dag32's Avatar

Join Date: Aug 2005
Location: SoCal
Posts: 1,567
Trader Rating: 100 (100%+)
Default

Quote:
Originally Posted by RedBullFiXX View Post
I had previously thought the Enetti would work, but, Jaco/Parma wheels have the most off-set, so if you want to keep it narrow, those are the best bet
Rear wheels will go right to the edge of the body, front wheels have too much off-set compared to the Tamiya wheels

Here are my recommendations based on test & racing so far
For Carpet Jaco Rear white dot, with Tamiya Option front
For Outdoor Tamiya Kit Rear, with Tamiya Option Front

Enetti are similar to the CRC wheels, with almost no off-set

Gratz to Dave Garcia with his new RM-01, hitting the podium at the TQ 2nd Anniversary Race
First time out with the car, looking good
Thanks Dave, the RM01 is really fun and easy to drive, with a little practice I hope to be able to drive it mo' better and mo' faster
__________________
★ David Garcia ★
dag32 is offline   Reply With Quote
Old 05-01-2012, 12:20 AM   #554
Tech Fanatic

bakaguyjean's Avatar

Join Date: Apr 2007
Location: Atsugi Japan
Posts: 823
Trader Rating: 1 (100%+)
Default

Quote:
Originally Posted by RedBullFiXX View Post
I had previously thought the Enetti would work, but, Jaco/Parma wheels have the most off-set, so if you want to keep it narrow, those are the best bet
Rear wheels will go right to the edge of the body, front wheels have too much off-set compared to the Tamiya wheels
Thanks fr the advise,I will keep searching
On a side note,here in Japan TCS does not allow any other placement of any of the front suspension besides the springs. This includes the servo saver and servo position. Its really an odd way of doing things but I think they do it to keep the car easy to drive and not so twitchy.
bakaguyjean is offline   Reply With Quote
Old 05-01-2012, 02:50 AM   #555
Tech Fanatic

Taman's Avatar

Join Date: Jun 2008
Location: GC, Aust
Posts: 833
Trader Rating: 64 (100%+)
Default

Somethings to look forward to:

54364 RM-01 Carbon Lower Deck
2.5mm thick carbon-fiber lower deck replaces kit-standard FRP component to increase overall chassis rigidity and bring out the chassis' maximum potential. It has an additional hole to allow installation of a small steering servo.

&

54365 RM-01 Carbon Lower Brace
2.5mm thick carbon-fiber lower brace replaces kit-standard FRP component to increase rigidity of the motor mount section for enhanced power transmission efficiency.


A TRF kit couldn't be too far off?
__________________
Toms 84C, Nissan R91CP, Porsche 956, TRF 417 V5.
Taman is offline   Reply With Quote
