Old 12-29-2008, 05:56 AM   #7981
Tech Initiate

Join Date: Dec 2008
Posts: 39
Default

Quote:
Originally Posted by xrayroooahhhh View Post
That's cause I set it up!!!!

I'm really starting to think that on our smooth carpet track.....you really don't need the oil dampers at all....my TT01 is "railed" running friction dampers....I think it's more important to get the right inserts....and springs!!!

R
I built my M03L. Only upgrades include ball bearings for the transmission and then super mini oil shocks. I am setup per rc-mini.net build instructions to run at a low race heigth with the control arms just about level with the ground. I put blue shocks up front and yellow in the rear.


So what is the key with adjusting springs/inserts on carpet?
k_h_d is offline   Reply With Quote
Old 12-29-2008, 10:25 AM   #7982
Tech Champion

monkeyracing's Avatar
R/C Tech Elite Subscriber

Join Date: Mar 2008
Location: SnowMexico
Posts: 5,836
Trader Rating: 10 (100%+)
Default

The photo page is up and running at karz.ca!

Have a look. It's mostly mini!
__________________
Stab it and steer.
monkeyracing is offline   Reply With Quote
Old 12-29-2008, 03:19 PM   #7983
Tech Elite

caltek1's Avatar

Join Date: Mar 2007
Posts: 3,354
Trader Rating: 33 (100%+)
Default

Jim,

Great pictures on your website. Looks like you have a good turn out for mini. I also like to see a grid comprising so many different mini body shells. The track looks tight and would reward clean driving. I like the fact that you allow cars to be changed from FWD to RWD, something that is different to our rules.

I must finish building my MO4 and give it a test run ,before I turn it into a shelf queen. The Civic and miata cars look excellent.

regards,

Calvin
caltek1 is offline   Reply With Quote
Old 12-29-2008, 05:31 PM   #7984
Tech Elite

Join Date: Oct 2006
Posts: 2,367
Default

Jim, that really looks great. YGPM
Granpa is offline   Reply With Quote
Old 12-29-2008, 07:32 PM   #7985
Super Moderator

charlie_b's Avatar
R/C Tech Elite Subscriber

Join Date: Aug 2001
Location: Anaheim
Posts: 9,592
Trader Rating: 1 (100%+)
Send a message via AIM to charlie_b Send a message via MSN to charlie_b Send a message via Yahoo to charlie_b
Default

Hey Socal Mini Drivers....



And more track pix....



If you guys aren't doing anything on New Year's Day(liek watching a parade) in Socal, please come on bye!
__________________
''Many of life's failures are people who did not realize how close they were to success when they gave up.''-- Thomas Alva Edison
CAL RACEWAY:CAL RACEWAY
GT10 SERIES:GT10 SERIES
CFX Paintworks:="https://www.facebook.com/CFXPaintworks?fref=ts
|HITEC|PARMA|PROTEKRC|SWEEP|IWATA|RPM|AMAIN|CREATE X/WICKED/AUTOAIR PAINTS|TEAMASSOCIATED|REEDY
charlie_b is offline   Reply With Quote
Old 12-29-2008, 07:52 PM   #7986
Tech Elite

tony gray's Avatar
R/C Tech Elite Subscriber

Join Date: Jun 2002
Location: Melbourne, Australia. Home of rc-mini.net
Posts: 3,210
Trader Rating: 4 (100%+)
Default

Now - Just WHAT is this thing? And what's it got to do with Minis?



Click HERE to find out if you really need a Speed Meter.....
tony gray is offline   Reply With Quote
Old 12-29-2008, 08:04 PM   #7987
Tech Champion

monkeyracing's Avatar
R/C Tech Elite Subscriber

Join Date: Mar 2008
Location: SnowMexico
Posts: 5,836
Trader Rating: 10 (100%+)
Default

Pretty damn cool machine, Tony. I had a similar idea for getting an idea of how fast cars were running based simply on output voltage from a motor/generator.

These guys did the math and got it sort of calibrated, too!

Way beyond my scope of smartitude.

Jim

PS: Damn Charlie, you've out-postered me! Now I need to notch it up a bit. Here's my last poster....

__________________
Stab it and steer.
monkeyracing is offline   Reply With Quote
Old 12-29-2008, 10:36 PM   #7988
Super Moderator

charlie_b's Avatar
R/C Tech Elite Subscriber

Join Date: Aug 2001
Location: Anaheim
Posts: 9,592
Trader Rating: 1 (100%+)
Send a message via AIM to charlie_b Send a message via MSN to charlie_b Send a message via Yahoo to charlie_b
Default

Gonna check out your site now...i wouldn't mind coming down and drivin out there.
__________________
''Many of life's failures are people who did not realize how close they were to success when they gave up.''-- Thomas Alva Edison
CAL RACEWAY:CAL RACEWAY
GT10 SERIES:GT10 SERIES
CFX Paintworks:="https://www.facebook.com/CFXPaintworks?fref=ts
|HITEC|PARMA|PROTEKRC|SWEEP|IWATA|RPM|AMAIN|CREATE X/WICKED/AUTOAIR PAINTS|TEAMASSOCIATED|REEDY
charlie_b is offline   Reply With Quote
Old 12-30-2008, 08:54 AM   #7989
Tech Elite

Join Date: Oct 2006
Posts: 2,367
Default

Beltran raceway is a great Mini track. Sure wish I could be there.

Charlie, let us know if you'll have any more events here.
Granpa is offline   Reply With Quote
Old 12-30-2008, 09:47 AM   #7990
MD
Tech Elite

MD's Avatar

Join Date: Aug 2005
Location: Illinois
Posts: 4,584
Trader Rating: 102 (100%+)
Default

I don't know if any of you were planning on attending the first TCS race in California, according to the TCS forum the date has been changed so that it doesn't conflict with the Super Bowl.
MD is offline   Reply With Quote
Old 12-30-2008, 02:14 PM   #7991
Tech Elite

SerpentCT4S's Avatar

Join Date: Dec 2007
Location: NYC
Posts: 2,847
Trader Rating: 94 (96%+)
Send a message via AIM to SerpentCT4S
Default

I just got my Tamiya aluminum shock set.

What weight oil should I run? I am running a stock M03, not racing or anything, just driving it around.



I was also looking at the 3Racing site for some more upgrades. I came across the front and rear graphite rear stiffener. Where do these parts mount? Do they replace an existing part or is it a new part? A picture would be great.

Last edited by SerpentCT4S; 12-30-2008 at 02:26 PM.
SerpentCT4S is offline   Reply With Quote
Old 12-30-2008, 03:12 PM   #7992
Tech Initiate

Join Date: Dec 2008
Posts: 39
Default

Pictures of my M03L. Mostly stock with transmission bearing upgrade and super mini oil shocks and tuning shocks. This is the first RC car body I have painted. It turned out pretty sloppy but the intent was to look like my 2003 Cooper S. I can't wait to get out and join the local racers.
Attached Thumbnails
Tamiya mini cooper-img_0043-large-.jpg   Tamiya mini cooper-img_0051-large-.jpg   Tamiya mini cooper-img_0032-large-.jpg   Tamiya mini cooper-img_0038-large-.jpg
k_h_d is offline   Reply With Quote
Old 12-30-2008, 03:49 PM   #7993
Tech Elite

caltek1's Avatar

Join Date: Mar 2007
Posts: 3,354
Trader Rating: 33 (100%+)
Default

SerpentCT4S,

For the Tamiya shocks 50 wt oil front and 40 Wt oil rear. I use three hole pistons front and rear. Ride height should be around 5mm front and 5/6mm rear. The lower the car is the less likely to traction roll.

3Racing front and rear graphite braces go across the top of the front and rear chassis and use the screw holes used for the top mounting point for the shocks. These are not legal for TCS racing but will not worry you for driving around.

3Racing front and rear hubs are softer than the Tamiya hubs. They will not take abuse and bend easily. I have had one degree rear hubs become 10 degree rear hubs from being hit by another racer at full noise.

I advise you to visit http://rc-mini.net/joomla/index.php. There is alot of useful information on the web site.

Regards,

Calvin
caltek1 is offline   Reply With Quote
Old 12-30-2008, 03:55 PM   #7994
Tech Elite

caltek1's Avatar

Join Date: Mar 2007
Posts: 3,354
Trader Rating: 33 (100%+)
Default

k_h_d,

Make sure you have some extra tyres. The kit radials wear out quickly. I have found that the tuning on my mini is mostly done with the tyres and then springs if needed.

Not sure if you are running TCS, if so you might want some 60D S grips and 60D's. Here in Aus most run Powers, Spice or rides.

Regards,

Calvin
caltek1 is offline   Reply With Quote
Old 12-30-2008, 04:06 PM   #7995
Tech Elite

SerpentCT4S's Avatar

Join Date: Dec 2007
Location: NYC
Posts: 2,847
Trader Rating: 94 (96%+)
Send a message via AIM to SerpentCT4S
Default

Quote:
Originally Posted by caltek1 View Post
SerpentCT4S,

For the Tamiya shocks 50 wt oil front and 40 Wt oil rear. I use three hole pistons front and rear. Ride height should be around 5mm front and 5/6mm rear. The lower the car is the less likely to traction roll.

3Racing front and rear graphite braces go across the top of the front and rear chassis and use the screw holes used for the top mounting point for the shocks. These are not legal for TCS racing but will not worry you for driving around.

3Racing front and rear hubs are softer than the Tamiya hubs. They will not take abuse and bend easily. I have had one degree rear hubs become 10 degree rear hubs from being hit by another racer at full noise.

I advise you to visit http://rc-mini.net/joomla/index.php. There is alot of useful information on the web site.

Regards,

Calvin
Thanks for the advice. I will take a look at the link you included.

I just got my shocks mounted back onto my car. I used 35 wt oil in all 4 and used the 2 hole pistons. These shocks seem shorter than the stock ones. I had to raise my body up one hole on my posts.

I might get the graphite braces. I dont plan on racing, so I dont have to worry if they are legal.

When I said aluminum hubs, I mean the wheel hexes. Instead of the plastic ones, I am going to get the aluminum ones.
SerpentCT4S is offline   Reply With Quote
