Old 12-21-2016, 08:46 AM   -   Wikipost
R/C Tech Forums Thread Wiki: Kyosho Ultima RB6 & RB6.6 Car Thread
Please read: This is a community-maintained wiki post containing the most important information from this thread. You may edit the Wiki once you have been a member for 90 days and have made 90 posts.

Last edit by: tobamiester
RB6.6 Kyosho America Product Page: http://www.kyoshoamerica.com/ULTIMA-...T_p_24505.html

RB6.6 Manual http://www.kyosho.com/jpn/support/in...A_RB6_6_IM.pdf

RB6.6 Kyosho Youtube https://www.youtube.com/watch?v=vW_sR667utY

MSRP $639 MAP $399.99

-------------------------------
New RB6.6 parts (compared exploded views, prices and links are Kyosho America):

Chassis:
  1. Main chassis - UM731 - $125.99
  2. Side guards - UM732 - $9.99

Battery Holder:
  1. Battery plate - UM733 - $8.99
  2. Battery foam - UM741 - $7.99

Rear Bulkheads:
  1. MM3 and Laydown - UM740 - $9.99
    • MM3 bulkhead
    • Laydown bulkhead
    • Swaybar Holders

3 Gear Transmission (MM and RM):
  1. Transmission - UM734 - $10.99
    • transmission cases
    • spacers
    • caps
    • plastic FR & RR suspension hangers

  2. Gear Cover - UM735 - $6.99

Laydown Transmission (3 and 4 gear possible):
  1. Transmission - UM736 - $10.99
    • transmission cases
    • spacers
    • caps
    • required extra hardware
    • pastic FR suspension hanger

  2. 40T idler - UM737 - $6.99
  3. Motor plate - UM738 - $18.99
  4. Gear cover - UM739 - $6.99

Body:
  1. Blade body - UMB05 - $27.99

Optional Parts:
  1. Lightweigt Blade body - UMB05LW - $31.99
  2. Aluminum FR suspension hanger - UMW705B - $28.99 (may be able to file UMW705 to fit)
  3. Brass FR suspension hanger - UMW725B - $30.99 (looks more different than UMW725..someone confirm?)

Typical Upgrades for new RB6.6 Buyers

UMW701 Aluminum Steering Plate (RB6)
UMW702 Aluminum Crank Arm (RB6)
UMW704-0 V2 Aluminum Rear Hub Set(0/RB6)
UMW705B Aluminum Rear Sus. Holder (RF/RB6.6) or brass UMW725B
UMW707 Aluminum Rear Sus. Holder (RR-Mid)

Nice to have:

UMW723 Aluminum Front Sus Block (Type B/10g/RB6/RT6/SC6).


Aftermarket Parts:

Front Wing: https://www.prolineracing.com/perfor...mount-alum-rb6

Print Wikipost

Like Tree17Likes
Reply

Thread Tools Search this Thread
Old 09-29-2012, 02:12 PM   #796
Moderator

Posvar's Avatar

Join Date: Nov 2009
Location: North Carolina by way of SoCal!
Posts: 4,604
Trader Rating: 462 (100%+)
Default

^^^do you have a part number for them????

Thanks.
__________________
Having fun with my 9 year old and running Kyosho cars!
Posvar is offline   Reply With Quote
Old 09-29-2012, 02:15 PM   #797
Moderator

Posvar's Avatar

Join Date: Nov 2009
Location: North Carolina by way of SoCal!
Posts: 4,604
Trader Rating: 462 (100%+)
Default

__________________
Having fun with my 9 year old and running Kyosho cars!
Posvar is offline   Reply With Quote
Old 09-29-2012, 02:17 PM   #798
Tech Elite

Join Date: Jun 2010
Location: Southern California
Posts: 2,167
Trader Rating: 77 (100%+)
Default

Quote:
Originally Posted by goin2drt View Post
I will post a pic later but all my stuff fit awesome. Shorty lipo is the key. I went 1015 servo, then my airtronics receiver. Lipo and then the LRP SXX fit perfect with the cap hidden under the shock tower.nothing had to go on the sides. All balanced right down the middle.
Here is mine. Not completed. I am going to shrink tube the wires black. I was surprised at how nice everything fit.
Kyosho Ultima RB6 & RB6.6 Car Thread-1.jpg

Kyosho Ultima RB6 & RB6.6 Car Thread-3.jpg

Kyosho Ultima RB6 & RB6.6 Car Thread-2.jpg
goin2drt is offline   Reply With Quote
Old 09-29-2012, 02:17 PM   #799
Tech Addict

steam's Avatar

Join Date: Sep 2010
Location: Buena Park
Posts: 560
Trader Rating: 9 (100%+)
Default

Quote:
Originally Posted by Posvar View Post
^^^do you have a part number for them????

Thanks.
Just cut the longer ones to the right length
__________________
Yokomo YZ-2, Kyosho Ultima SC-R, RT5, Airtronics M12
steam is offline   Reply With Quote
Old 09-29-2012, 02:26 PM   #800
Tech Addict

steam's Avatar

Join Date: Sep 2010
Location: Buena Park
Posts: 560
Trader Rating: 9 (100%+)
Default

Quote:
Originally Posted by goin2drt View Post
Here is mine. Not completed. I am going to shrink tube the wires black. I was surprised at how nice everything fit.
Attachment 975742

Attachment 975744

Attachment 975743
Looks good, I have a Lo profile servo, but this is pretty much the set up I'm going with.
__________________
Yokomo YZ-2, Kyosho Ultima SC-R, RT5, Airtronics M12
steam is offline   Reply With Quote
Old 09-29-2012, 03:22 PM   #801
Tech Regular

azz28's Avatar

Join Date: Oct 2010
Location: Gold coast , QLD
Posts: 456
Trader Rating: 30 (100%+)
Default

Quote:
Originally Posted by jpcopeland1 View Post
During racing at OC/RC last night Tater and Chris stripped out ball studs from their front hub carriers. Only fix was to install the longer ball studs which I have on order. Has anyone else had this problem. They went 1-2 in modified, First Chris, then Tater.
funny u should mention this my mate had two ball studs strip straight out of the rear bulkhead the other night..... not from a shunt either weird .... so i have put longer ones in mine also with a nut on them !!
__________________
Kyosho RB6 & RB5 WC| Orion r10 pro- Vortex Vst 8.5t | KO Propo |

Kyosho MP9 TKI3 |OS Engines| Byron ProDriver Gen2| KO Propo |
azz28 is offline   Reply With Quote
Old 09-29-2012, 04:47 PM   #802
Tech Elite

t8rtot's Avatar

Join Date: Nov 2008
Posts: 2,010
Trader Rating: 14 (94%+)
Default

Has anyone mounted saddles sideways with the car in rear motor? Pics?
__________________
Sfida

Last edited by t8rtot; 09-29-2012 at 04:57 PM.
t8rtot is offline   Reply With Quote
Old 09-29-2012, 06:01 PM   #803
Tech Prophet

Join Date: Dec 2009
Location: Tega Cay, SC / Charlotte
Posts: 15,137
Trader Rating: 1069 (100%+)
Default

Quote:
Originally Posted by t8rtot View Post
Has anyone mounted saddles sideways with the car in rear motor? Pics?
I'm gonna try it, but won't have it built for a week or so... Will have RS Pro, 614ff, and BLS551 low pro servo.
__________________
Less warning labels... more Darwin!
EZ Customs Paint / Xtreme RC
ON ROAD: XRAY T4 '15 USVTA/USGT X1 F1 , OFF ROAD RB6
and for those that don't know me.. I'm a sarcastic A DBL S
Dave Cates Founder of www.GO-RCing.org
bigwavedave33 is offline   Reply With Quote
Old 09-29-2012, 07:05 PM   #804
Tech Master

mdowney's Avatar
R/C Tech Elite Subscriber

Join Date: Jun 2010
Location: Seattle, WA
Posts: 1,562
Trader Rating: 21 (100%+)
Default

Quote:
Originally Posted by jpcopeland1 View Post
During racing at OC/RC last night Tater and Chris stripped out ball studs from their front hub carriers. Only fix was to install the longer ball studs which I have on order. Has anyone else had this problem. They went 1-2 in modified, First Chris, then Tater.
Quote:
Originally Posted by azz28 View Post
funny u should mention this my mate had two ball studs strip straight out of the rear bulkhead the other night..... not from a shunt either weird .... so i have put longer ones in mine also with a nut on them !!
If you're having trouble with ball studs stripping out you can also put grub screws in the empty holes. This also makes your bulkhead more sturdy. The manual actually tells you to do this in the rear but you can do it in the front too.
__________________
Mike Downey
--
I try all of the RC kits and usually race at Tacoma RC Raceway
mdowney is offline   Reply With Quote
Old 09-29-2012, 07:40 PM   #805
Tech Elite

savageboy69's Avatar
R/C Tech Elite Subscriber

Join Date: Dec 2006
Location: Pasco,WA
Posts: 3,933
Trader Rating: 88 (100%+)
Default

Quote:
Originally Posted by t8rtot View Post
Has anyone mounted saddles sideways with the car in rear motor? Pics?
My saddles will be here Monday and ill post some pics
__________________
Xray|Rc America|Hudy|FX engines|Tekin|SOR graphics|LFR|Ogio|SRT servos|
XB8 2016
XB8-E 2016
XB4 2017
savageboy69 is offline   Reply With Quote
Old 09-29-2012, 08:39 PM   #806
Tech Elite
R/C Tech Elite Subscriber

Join Date: Aug 2010
Location: Anaheim Ca.
Posts: 3,927
Trader Rating: 138 (100%+)
Default

Quote:
Originally Posted by mdowney View Post
If you're having trouble with ball studs stripping out you can also put grub screws in the empty holes. This also makes your bulkhead more sturdy. The manual actually tells you to do this in the rear but you can do it in the front too.
I've done that to mine. Hope it keeps from happening tomorrow.
__________________
TLR 22T 3.0, 2X Yokomo YZ-2 DTM, B64D (Temporary 4 wheel) YZ-4 SF (please hurry), Mugen MBX7R Eco, Hobbywing, Futaba, LRH Hobbies, Amain Hobbies, iCharger.
jpcopeland1 is offline   Reply With Quote
Old 09-29-2012, 08:57 PM   #807
Tech Master

mdowney's Avatar
R/C Tech Elite Subscriber

Join Date: Jun 2010
Location: Seattle, WA
Posts: 1,562
Trader Rating: 21 (100%+)
Default

Also, don't over-tighten your ball studs when you screw them in. And if you're using a electric screw driver, go slow so the plastic doesn't over-heat and set your clutch low. I like to use a wrench for the last few turns so I don't strip the bulkhead.
__________________
Mike Downey
--
I try all of the RC kits and usually race at Tacoma RC Raceway
mdowney is offline   Reply With Quote
Old 09-29-2012, 09:10 PM   #808
Tech Master

mdowney's Avatar
R/C Tech Elite Subscriber

Join Date: Jun 2010
Location: Seattle, WA
Posts: 1,562
Trader Rating: 21 (100%+)
Default

Quote:
Originally Posted by Derry View Post
If Kyosho made an front alum pivot block I would buy it!
I've never broken a front pivot block and you're a better driver than me. I think you're safe with the kit plastic.
__________________
Mike Downey
--
I try all of the RC kits and usually race at Tacoma RC Raceway
mdowney is offline   Reply With Quote
Old 09-29-2012, 09:16 PM   #809
Tech Master

mdowney's Avatar
R/C Tech Elite Subscriber

Join Date: Jun 2010
Location: Seattle, WA
Posts: 1,562
Trader Rating: 21 (100%+)
Default

(Yes, I know about multi-quote. Just reading back through old posts. Sorry...)

I mounted my Futaba Rx, which is bigger than the KO, right side up along the side of the battery. I just layered up about eight pieces of servo tape to build a flat spot for the Rx. Seems to work fine. We'll see if it holds up. Mounted the R10 capacitor opposite the Rx but in its side. Power switch mounts vertically on the side of the rear bulkhead behind the ESC on the right side.

I think this is what Jared did too.

Mike


Quote:
Originally Posted by savageboy69 View Post
wondering how others mounted there reciever? heres a pic of mine i made a piece out of lexan that drops down 4mm for a little extra clearance for the ko reciever
__________________
Mike Downey
--
I try all of the RC kits and usually race at Tacoma RC Raceway
mdowney is offline   Reply With Quote
Old 09-29-2012, 10:10 PM   #810
Tech Elite
R/C Tech Elite Subscriber

Join Date: Aug 2010
Location: Anaheim Ca.
Posts: 3,927
Trader Rating: 138 (100%+)
Default

Quote:
Originally Posted by Posvar View Post
^^^do you have a part number for them????

Thanks.
KYOUM128
__________________
TLR 22T 3.0, 2X Yokomo YZ-2 DTM, B64D (Temporary 4 wheel) YZ-4 SF (please hurry), Mugen MBX7R Eco, Hobbywing, Futaba, LRH Hobbies, Amain Hobbies, iCharger.
jpcopeland1 is offline   Reply With Quote
